用于湖州市长兴县南太湖的路灯EEI分析数据

在灯具出厂前，采集用于湖州市长兴县南太湖的路灯的性能参数，分析该类型灯具的能效指数EEI，从而确定灯具的能效等级，以适用于该特定场景下的照明需求，指导灯具优化设计方案，提高灯具的节能性能和使用寿命。1.数据来源：在灯具出厂前，随机抽取用于湖州市长兴县南太湖的路灯的成品，采集该路灯输入电压、电流、光通量和功率因子等参数。 2.数据处理 (1)基于采集的参数对灯具进行能效等级EEI分析： EEI=P*PF/Pref=IV*PF/Pref； 其中P是灯具的额定功率，PF是功率修正因子；Pref是灯的参考功率，Φuse为灯的有效光通量。 当Φuse<1300lm时：Pref =0.88√Φuse +0.049 Φuse 当Φuse≥1300lm时：Pref =0.07341Φuse (2)若EEI≤0.11，为A++级；0.11≤EEI≤0.17，为A+级；0.17≤EEI≤0.24，为A级；0.24≤EEI≤0.6，为B级；0.6≤EEI≤0.8，为C级；0.8≤EEI≤0.95，为D级；EEI>0.95，为E级。 3.数据应用： 能效指数是评估灯具能效的重要指标之一，灯具出厂前进行等效分析，以适配湖州市长兴县南太湖的路灯应用场景下的照明需求；同时也可为厂商优化灯具设计方案提供数据支撑，提高灯具的节能性能和使用寿命。

Prior to leaving the factory, performance parameters of street lamps intended for South Taihu Lake, Changxing County, Huzhou City are collected, and the Energy Efficiency Index (EEI) of this type of luminaire is analyzed to determine the energy efficiency grade of the luminaire, so as to meet the lighting demands of this specific scenario, guide the optimized design of luminaires, and improve their energy-saving performance and service life.

1. Data Source:
Finished street lamp products intended for South Taihu Lake, Changxing County, Huzhou City are randomly sampled before leaving the factory, and parameters such as input voltage, current, luminous flux and power factor of the street lamps are collected.

2. Data Processing
(1) Conduct energy efficiency grade EEI analysis for luminaires based on the collected parameters:
EEI = P × PF / Pref = IV × PF / Pref;
Where P is the rated power of the luminaire, PF is the power factor, Pref is the reference power of the luminaire, and Φ_use is the effective luminous flux of the luminaire.
When Φ_use < 1300 lumens: Pref = 0.88√Φ_use + 0.049Φ_use;
When Φ_use ≥ 1300 lumens: Pref = 0.07341Φ_use.
(2) Determine the energy efficiency grade according to EEI:
If EEI ≤ 0.11: Grade A++;
If 0.11 ≤ EEI ≤ 0.17: Grade A+;
If 0.17 ≤ EEI ≤ 0.24: Grade A;
If 0.24 ≤ EEI ≤ 0.6: Grade B;
If 0.6 ≤ EEI ≤ 0.8: Grade C;
If 0.8 ≤ EEI ≤ 0.95: Grade D;
If EEI > 0.95: Grade E.

3. Data Application:
The Energy Efficiency Index (EEI) is one of the key indicators for evaluating luminaire energy efficiency. Conducting equivalent analysis on luminaires before they leave the factory can adapt to the lighting requirements of the street lamp application scenario at South Taihu Lake, Changxing County, Huzhou City. Meanwhile, it can provide data support for manufacturers to optimize luminaire design schemes, thereby improving the energy-saving performance and service life of luminaires.
