corrosion data of pure metals (Ni and Ti) and alloys (316H SS and GH3535) in liquid GaInSn

The interactions between GaInSn, and several metal materials, including pure metals (Ni and Ti) and alloys (316H stainless steel (SS) and GH3535), at 650 °C were investigated. The composition of materials before corrosion are listed in Table 1 and 2. Specimens of Ni (8.0 mm × 8.0 mm × 2.0 mm), Ti (10.0 mm × 8.0 mm × 1.2 mm), 316 H SS (10.0 mm × 8.0 mm × 2.0 mm), and GH3535 alloys (9.0 mm × 9.0 mm × 2.0 mm) were placed into quartz tubes with dimensions of 250 mm (length) × 20 mm (diameter). The specimens were then heated at 650 °C for 5 h. After corrosion in GaInSn, the composition of specimens were listed in Table 3 to 6. The weight changes and XRD data of samples can be found in uploaded files.

研究了650°C下镓铟锡（GaInSn）与多种金属材料的相互作用，这些材料包括纯金属（镍（Ni）、钛（Ti））和合金（316H不锈钢（SS）、GH3535合金）。腐蚀前各材料的成分列于表1和表2。将镍（Ni，尺寸为8.0 mm×8.0 mm×2.0 mm）、钛（Ti，尺寸为10.0 mm×8.0 mm×1.2 mm）、316H不锈钢（SS，尺寸为10.0 mm×8.0 mm×2.0 mm）和GH3535合金（尺寸为9.0 mm×9.0 mm×2.0 mm）试样放入尺寸为250 mm（长）×20 mm（直径）的石英管中。随后将试样在650°C下加热5小时。在GaInSn中腐蚀后，试样的成分列于表3至表6。样品的重量变化和X射线衍射（XRD）数据可在上传文件中找到。

搜集汇总

背景与挑战

背景概述

该数据集总结了纯金属（镍和钛）和合金（316H不锈钢和GH3535）在650°C液态GaInSn中腐蚀5小时的实验数据。它包括腐蚀前后材料的成分分析、试样尺寸细节，以及重量变化和XRD结果，适用于研究高温液态金属环境下的材料腐蚀行为。
