旋转式线束热缩管均匀加热设备设计数据集

1、数据设计：从设计工具中定义设备零件类型、尺寸、结构方式；零件类型包括热风枪、电机和夹持线缆的转动装置，夹持线缆的转动装置含有夹持、滑防设备，可适合多种尺寸的线束，将线束置于转动装置的指定位置；
2、数据处理：通过三维设计软件将设计数据模拟为加热设备模型，模拟不同材质的热缩管进行控制处理，控制电机的转速和角度，分析加热均匀效果。
3、数据应用：可用于不同尺寸的线束进行热缩管均匀加热，保障热缩管与线束的紧密贴合。

1. Data Design: Define the types, dimensions and structural configurations of equipment parts via design tools. The types of parts include hot air guns, motors and rotary cable-clamping devices, which are equipped with clamping and anti-slip components, compatible with wire harnesses of various sizes and enabling the placement of wire harnesses at their designated positions.
2. Data Processing: Simulate the design data into a heating equipment model through 3D design software, perform control processing by simulating heat-shrink tubes of different materials, control the rotation speed and angle of the motor, and analyze the heating uniformity effect.
3. Data Application: This dataset can be applied to uniformly heat heat-shrink tubes on wire harnesses of different sizes, so as to ensure the tight adhesion between the heat-shrink tubes and the wire harnesses.

搜集汇总

背景与挑战

背景概述

该数据集由贵州航天电器股份有限公司自行产生，属于制造业领域，数据规模为130KB，无更新周期。数据集设计用于自动调节热风枪功率、电机转速与夹持转动角度，以实现热缩管的均匀加热，适用于高精装备领域的高可靠线束批量生产。
