总线型数字式控制器控制模块数据集

总线型数字式控制器控制模块数据集根据分布式独立电液执行机构控制系统的软硬件参数，建立AMESim电控、液压和机械结构仿真模型，进行动臂和斗杆的单动作仿真并输出不同目标流量和不同载荷下各回路中压力、流量、速度、位移等仿真数据，满足总线型数字式控制器流量控制模块要求，数据保存为xlsx格式文件。文件夹包含分布式独立电液执行机构仿真模型以及压力、流量、速度、位移等仿真数据表格。根据控制器的参数搭建仿真模型，进行斗杆的单动作仿真并输出空载、满载（200kg）、重载（300kg）工况下12L/min、24L/min、36L/min目标流量的压力、流量、速度、位移等仿真数据。
泵阀复合高动态高精度控制模型由amesim软件搭建，大小为35.75MB；泵阀复合高动态高精度控制策略仿真数据集文件大小为1.68MB共有9个子表，分别为空载、200kg、300kg在不同目标流量下（12L/min,24L/min,36L/min）的仿真数据。

The dataset for the bussed digital controller control module develops AMESim-based electrical control, hydraulic and mechanical structure simulation models based on the software and hardware parameters of the distributed independent electro-hydraulic actuator control system. It performs single-action simulations of the boom and stick, and outputs simulation data including pressure, flow rate, velocity and displacement in each circuit under various target flow rates and loads, which satisfies the requirements of the flow control module of the bussed digital controller. All data is stored in XLSX format files. The folder contains the simulation model of the distributed independent electro-hydraulic actuator and simulation data tables covering pressure, flow rate, velocity, displacement and other related parameters. Based on the controller's parameters, a simulation model is constructed, and single-action simulations of the stick are carried out to output simulation data including pressure, flow rate, velocity and displacement under target flow rates of 12L/min, 24L/min and 36L/min under no-load, full load (200kg) and heavy load (300kg) operating conditions. The pump-valve composite high-dynamic and high-precision control model is built using AMESim software, with a size of 35.75 MB. The simulation dataset of the pump-valve composite high-dynamic and high-precision control strategy has a file size of 1.68 MB and includes 9 sub-tables, which correspond to the simulation data under no-load, 200kg and 300kg loads with different target flow rates (12L/min, 24L/min, 36L/min) respectively.

搜集汇总

背景与挑战

背景概述

该数据集基于分布式独立电液执行机构控制系统的软硬件参数，利用AMESim软件建立仿真模型，生成不同目标流量和载荷下的压力、流量、速度、位移等仿真数据，以支持总线型数字式控制器的流量控制模块需求。数据以xlsx、ame和docx格式存储，总大小为37.61MB，源自国家重点研发计划项目'挖掘机分布式独立电液控制系统关键技术研究'。
