三维电磁正演模拟精度验证数据

本数据集涉及三维电磁正演模拟精度验证研究过程中的质量控制。课题方使用课题研发的三维电磁正演程序计算均匀半空间模型的电磁响应。专家通过对比三维数值模拟结果与一维数值模拟结果之间的差异，对精度指标进行测评。利用Comsol软件对均匀半空间模型进行空间单元离散；设计发射源长度、发射电流强度和接收点位置等输入信息，形成三维电磁正演输入文件；运行本课题研发的三维数值模拟程序，计算获得均匀半空间地电模型电磁响应。计算电磁三维正演计算误差；对比一维和三维数值模拟结果响应曲线特征，分析三维数值模拟结果的可靠性。
由具有CNAS等专业资质的第三方机构“吉林省电子信息产品检验研究院”参考“GB/T25000.51-2016”和“GB/T25000.23-2019”执行标准，严格按照专家论证的测试大纲进行检验测试，通过实验试验方式产生，检测结果经组织专家论证并最终确认。
数据量：4MB

This dataset relates to quality control during the accuracy validation study of 3D electromagnetic forward modeling.
The research team used the 3D electromagnetic forward modeling program developed by the project to calculate the electromagnetic response of a homogeneous half-space model. Experts evaluated the accuracy indicators by comparing the differences between 3D numerical simulation results and 1D numerical simulation results. The homogeneous half-space model was spatially discretized using COMSOL software; input information such as transmitter length, transmitting current intensity, and receiver position were designed to form the 3D electromagnetic forward modeling input files. The 3D numerical simulation program developed by the project was run to calculate and obtain the electromagnetic response of the homogeneous half-space geoelectric model. The error of the 3D electromagnetic forward modeling was calculated; the response curve characteristics of the 1D and 3D numerical simulation results were compared to analyze the reliability of the 3D numerical simulation results.

The dataset was generated via experimental tests by the third-party institution Jilin Provincial Institute of Electronic Information Product Inspection, which possesses professional qualifications including CNAS. The institution conducted inspection and testing strictly in accordance with the expert-validated test outline, referencing the implementation standards GB/T 25000.51-2016 and GB/T 25000.23-2019. The test results were reviewed and finally confirmed by a panel of experts.

Data size: 4 MB

搜集汇总

背景与挑战

背景概述

该数据集用于三维电磁正演模拟的精度验证研究，通过对比一维与三维数值模拟结果来评估精度指标。数据由第三方机构依据国家标准检验测试生成，涉及均匀半空间模型的电磁响应计算。
