网格和曲面高精度逼近测试库

本数据集主要面向网格和曲面高精度逼近算法的研究，包括四边形曲面片参数化表达功能、三角形网格四边形化功能、复杂曲面片体的整体偏置功能、构造光滑NURBS曲面与由边界曲线生成曲面功能的测试。四边形曲面片参数化表达测试库构建了obj格式的测试用例文件200个；三角形网格四边形化测试库构建了obj格式的测试样例共1534个，包含CAD模型和汽车零件模型，每个样例包括一个原始三角网格模型和四边形网格模型，其中四边形网格模型由基于方向场的四边形网格化方法生成；复杂车身曲面整体偏置测试库包括数据来源分别为车身内板相关模型及复杂车身及零部件相关模型共计1000个，每个样例包括四个简单B样条曲面片;由边界曲线生成曲面库构建了txt格式测试样例43个，样例包括从B样条曲面上提取的B样条曲线。

This dataset is primarily targeted at research on high-precision approximation algorithms for meshes and surfaces, including tests for quadrilateral surface patch parameterization, triangle mesh quadrangulation, global offset of complex surface patch bodies, construction of smooth NURBS surfaces, and surface generation from boundary curves. The quadrilateral surface patch parameterization test library contains 200 test case files in OBJ format; the triangle mesh quadrangulation test library includes a total of 1534 test samples in OBJ format, covering CAD models and automotive part models, with each sample consisting of an original triangular mesh model and a quadrilateral mesh model generated via a direction-field-based quadrangulation method; the global offset test library for complex automotive body surfaces comprises 1000 samples sourced from body inner panel-related models and complex automotive body and component-related models respectively, with each sample containing four simple B-spline surface patches; the surface generation from boundary curves test library includes 43 test samples in TXT format, with each sample containing B-spline curves extracted from B-spline surfaces.

搜集汇总

背景与挑战

背景概述

本数据集旨在支持网格和曲面高精度逼近算法的研究，提供了四边形曲面片参数化、三角形网格四边形化、复杂曲面片体整体偏置等功能的测试用例。它包含多个测试库，涵盖OBJ、TXT等格式的数千个样例文件，数据量达1.38GB。
