高速列车典型零部件全生命周期应用验证数据集

本数据集收集项目研究期间进行在高速列车车体的结构碰撞安全性分析、流-固耦合分析和高速列车转向架的强度、刚度和模态分析的全流程数据，主要内容为开源流体求解器Su2、高速列车高速列车车体碰撞计算模型、高速列车转向架计算模型和求解过后求解结果文件的采集，旨在通过高速列车工程算例，对自研显式有限元接触碰撞算法点-面接触、面-面接触、自研隐式求解器刚度、强度和模态和集成流固耦合求解功能进行应用验证。实验结果表明自研显式求解器和自研隐式求解器在效率上优于主流商业软件，误差均在允许范围内。该数据集为原型系统开发的验证提供了有力支撑，为新一代高速列车典型零部件设计开发全生命周期中形成高效并行CAE分析提供了应用示范。

This dataset collects full-process data generated during the research project, covering structural crash safety analysis and fluid-structure coupling analysis of high-speed train bodies, as well as strength, stiffness and modal analysis of high-speed train bogies. Its core collected contents include the open-source fluid solver Su2, computational models for high-speed train body crashes and bogies, as well as post-solution result files. The purpose of this dataset is to conduct application verification for self-developed explicit finite element contact collision algorithms (including point-to-surface and surface-to-surface contact), the self-developed implicit solver for stiffness, strength and modal analysis, and the integrated fluid-structure coupling solving function, using high-speed train engineering calculation cases. Experimental results demonstrate that both the self-developed explicit and implicit solvers outperform mainstream commercial software in terms of computational efficiency, with all errors within the allowable range. This dataset provides strong support for the verification of prototype system development, and offers an application demonstration for efficient parallel CAE analysis throughout the full life cycle of design and development for typical components of new-generation high-speed trains.

搜集汇总

背景与挑战

背景概述

该数据集汇集了高速列车车体碰撞分析、流-固耦合分析及转向架强度、刚度和模态分析的全流程数据，包含开源求解器、计算模型与求解结果。它旨在通过工程算例验证自研显式和隐式求解器的性能，验证结果显示其效率优于主流商业软件且误差可控。该数据集为原型系统开发和高效并行CAE分析提供了应用示范与支撑。
