弹性光网络中基于非线性效应的Star-8QAM信号全光格式转换-原始数据

本数据集主要面向全光格式转换的研究，主要仿真了星型8QAM信号在弹性光网络中基于非线性效应的全光格式转换功能。数据来源于计算仿真，包括MZI输出功率随输入功率、相移、衰减的变化关系以及输入星型8QAM和输出QPSK信号的星座图、相位直方图和幅度直方图，不同输入OSNR条件下输入星型8QAM、解聚合的QPSK和OOK信号以及重新聚合的星型8QAM信号的误差矢量幅度和误比特率，QPSK和OOK在不同功率比下聚合得到的内圈和外圈具有不同功率比的星型8QAM信号星座图，QPSK和OOK信号聚合得到的内圈和外圈星座具有不同功率比的星型8QAM信号的误差矢量幅度和误比特率等计算仿真数据。数据量6.63MB。

This dataset is primarily developed for research on all-optical format conversion. It primarily simulates the all-optical format conversion functionality based on nonlinear effects for star-shaped 8QAM signals in elastic optical networks (EONs). The data is derived from computational simulations, including the relationship between the output power of a Mach-Zehnder Interferometer (MZI) and input power, phase shift, and attenuation; constellation diagrams, phase histograms, and amplitude histograms of the input star-shaped 8QAM and output QPSK signals; error vector magnitude (EVM) and bit error rate (BER) of the input star-shaped 8QAM signals, deaggregated QPSK and OOK signals, and reaggregated star-shaped 8QAM signals under different input optical signal-to-noise ratio (OSNR) conditions; constellation diagrams of star-shaped 8QAM signals with distinct power ratios for their inner and outer rings, which are generated by aggregating QPSK and OOK signals at varying power ratios; and the EVM and BER of such star-shaped 8QAM signals with different power ratios for their inner and outer constellation rings. The total size of this dataset is 6.63 MB.

搜集汇总

背景与挑战

背景概述

该数据集聚焦于全光格式转换研究，通过计算仿真模拟了弹性光网络中基于非线性效应的星型8QAM信号全光格式转换过程。它包含输出功率变化、星座图、误差矢量幅度和误比特率等仿真数据，数据量约为6.63MB。
