紧固件数字库-DIN931-2-87螺栓编码管理数据

本数据有助于紧固件DIN931-2-87螺栓产品属性管理及产品唯一简化编码生成和管理，实现产品的唯一性匹配。十二角螺钉产品属性繁多有如：产品类目、产品标准名称、产品标准代号、产品规格（由直径、长度、牙距、牙型组成）、材质、强度、材料、表面处理等12个属性构成，本数据通过将产品12个属性名称和属性值进行统一规范的管理，产品描述的所有属性值多的长达50个文字以上，很难在后续的ERP、WMS、MES等系统中调用和描述，并且无法进行产品唯一性的匹配和管理，为此将产品的12个属性值通过类似于Base64 的自定义编码（仅包含字母和数字一共33个）的方式转换成12~19位长的产品唯一编码实现产品的唯一性匹配和检索，并且通过产品的唯一性编码生成一个对于的产品二维码，快速的进行扫码识别进行后续系统平台的调用。1、数据采集： 通过发行的紧固件标准手册、螺纹公差、机械性能、材质手册等，获得紧固件DIN931-2-87螺栓产品的属性数据和参数，从本单位开发运营的“工业零部件数字库-【紧固件】标准底层系统”上采集紧固件产品的属性数据，包括：标准名称、标准代号、产品规格（细化为直径、长度、牙距、牙型等四项）、材质、强度、材料、材料化学成分、材料机械性能、表面处理等并生成属性对应的ID代号。 2、算法加工方法： 第一步：从工业零部件数字库-紧固件中获取产品数据，包括品类、标准【标准名称和标准代号】、规格（由直径、长度、牙距、牙型组成）以及材质、强度、材料、表色等数据及属性对应的ID代号。 第二步：将获取的品类、标准、规格3个属性的的ID号，使用33位自定义编码（仅含字母和数字：H1VGSCNXQTF6L7MR2UB04ZP89JE5Y3DKWA）转换成特定的短编码。 第三步：将获取的材质、强度、材料、表色属性值字符串通过哈希算法得到哈希值，再将哈希值使用33位自定义编码转换成特定的短编码。 第四部：将步骤二、三转换后获得的，品类、标准、规格及其他属性的自定义短码通过横杠连接在一起形成产品的唯一编码。

This dataset facilitates the attribute management, unique simplified coding generation and management, as well as unique matching for fastener DIN931-2-87 bolts. 12-point screws have a wide range of attributes, totaling 12 categories including product category, product standard name, product standard code, product specification (composed of diameter, length, pitch, thread profile), material, strength, base material, surface treatment and others. Previously, standardized management was conducted for the 12 attribute names and their values, but some product description attribute values could be over 50 characters long, making it difficult to call and describe in subsequent ERP, WMS, MES and other systems, and failing to realize unique product matching and management. To solve this issue, the 12 attribute values are converted into a 12-to-19-bit unique product code via a custom encoding similar to Base64 (only containing 33 letters and numbers: H1VGSCNXQTF6L7MR2UB04ZP89JE5Y3DKWA), so as to achieve unique product matching and retrieval. Meanwhile, a corresponding product QR code is generated based on the unique product code, enabling quick scanning and calling by subsequent system platforms.

1. Data Collection
Attribute data and parameters of fastener DIN931-2-87 bolts are acquired from published fastener standard manuals, thread tolerance specifications, mechanical property specifications, material manuals and other reference materials. Additionally, fastener product attribute data is collected from the "Industrial Component Digital Library - [Fasteners] Standard Underlying System" developed and operated by our team, including standard name, standard code, product specification (refined into four items: diameter, length, pitch, thread profile), material, strength, base material, material chemical composition, material mechanical properties, surface treatment, and corresponding ID codes are generated for each attribute.

2. Algorithm Processing Method
Step 1: Retrieve product data from the Industrial Component Digital Library - Fasteners, including category, standard [standard name and standard code], specification (composed of diameter, length, pitch, thread profile), as well as data of material, strength, base material, surface treatment and their corresponding ID codes.
Step 2: Convert the ID numbers of the three attributes of category, standard and specification into a specific short code using the 33-character custom encoding (only containing letters and numbers: H1VGSCNXQTF6L7MR2UB04ZP89JE5Y3DKWA).
Step 3: Calculate the hash value of the attribute value strings of material, strength, base material and surface treatment via a hash algorithm, then convert the hash value into a specific short code using the same 33-character custom encoding.
Step 4: Connect the custom short codes of category, standard, specification and other attributes obtained from Step 2 and Step 3 with hyphens to form the final unique product code.

搜集汇总

数据集介绍

特点

该数据集专注于DIN931-2-87标准螺栓的编码管理，包含1002条记录，每周更新。通过自定义编码方法，将产品的多个属性转换为唯一编码，便于系统管理和检索。
