气象参数、组件部件、构造节点数据库数据集

本数据集主要面向气象参数、组件部件以及构造节点数据库研究需求建设，主要记录了气象参数、组件部件、构造节点数据库数据。其中，气象参数数据库数据覆盖中国 5 类建筑热工设计分区、31 个省份、778 个典型城市的典型年气象参数，包括时间（年、月、日、时、分）、干球温度、露点温度、相对湿度、水平总辐照量、直射辐照量、散射辐照量、风向、风速信息；组件部件数据库包括 6694 款光伏组件、490 款逆变器、53 款蓄电池等建筑光伏系统关键设备参数信息，包含了安装方式、防水等级、防火等级等建筑设计用信息；构造节点数据库包括 30 种建筑光伏构造节点的节点平面图、节点立面图、节点剖面图、安装标准图和构配件标准图。本数据集的数据量为487MB。This dataset is developed to address research needs for meteorological parameters, component parts and construction joint databases, and primarily records data from three core databases: the meteorological parameter database, component parts database and construction joint database. The meteorological parameter database covers typical annual meteorological parameters of 778 typical cities across 31 provinces and 5 building thermal design zoning categories in China, including time data (year, month, day, hour, minute), dry-bulb temperature, dew point temperature, relative humidity, horizontal total solar irradiance, direct solar irradiance, diffuse solar irradiance, wind direction and wind speed information. The component parts database contains key equipment parameter information for building photovoltaic systems, including 6694 photovoltaic (PV) modules, 490 inverters and 53 batteries, as well as architectural design-related information such as installation method, waterproof rating and fire resistance rating. The construction joint database includes joint floor plans, joint elevations, joint section drawings, standard installation drawings and standard drawings of building components and accessories for 30 types of building photovoltaic construction joints. The total data size of this dataset is 487 MB.

搜集汇总

背景与挑战

背景概述

该数据集面向建筑光伏系统研究，包含气象参数、组件部件和构造节点三类数据。气象参数覆盖中国778个典型城市，组件部件涵盖光伏系统关键设备，构造节点提供建筑光伏构造图纸。数据总量为487MB。
