射频连接器国产化特征数据集

1、数据采集：从不同的产品设计文档中提取所有的射频连接器技术指标，如电器性能、机械性能、环境性能、材料和镀层，确定客户需求，如：主称代号、接触件各类、连接器外形结构、外导体安装形式、端接形式。
2、数据处理：根据接触件各类、连接器外形结构、外导体安装形式、端接形式等特征进行分类，根据分类的规则和分类结果确定主称代号；不同的主称代号对应不同的安装形式（表贴、穿墙、直插焊接等）、端接形式、匹配电缆类型和规格等；根据主称代号定位尺寸说明、安装示意图。
3、数据应用：对射频连接器国产化提供层级筛选功能，便于研发设计和销售时，选择与装备整机匹配的国产化连接器，实现从基本参数到详细参数的选择。

1. Data Collection: Extract all technical specifications of RF connectors from diverse product design documents, covering electrical performance, mechanical performance, environmental performance, materials and plating. Identify customer requirements including main designation codes, contact types, connector shape and structure, outer conductor mounting modes, and termination forms. 2. Data Processing: Classify the dataset based on characteristics such as contact types, connector shape and structure, outer conductor mounting modes and termination forms. Determine the main designation codes in accordance with classification rules and classification outcomes; different main designation codes correspond to distinct mounting modes (surface mount, through-wall, straight plug welding, etc.), termination forms, matching cable types and specifications, etc.; locate dimension descriptions and installation schematics via the main designation codes. 3. Data Application: Offer hierarchical screening functions for the localization of RF connectors, to facilitate the selection of domestically manufactured connectors compatible with complete equipment during R&D, design and sales, thus enabling the selection workflow from basic parameters to detailed parameters.

搜集汇总

背景与挑战

背景概述

该数据集由贵州航天电器股份有限公司自行产生，专注于射频连接器的国产化特征，适用于微波通讯、航天航海、武器系统和微波测量设备等高端制造领域的替代场景。数据集规模为47157KB，无定期更新，通过从产品设计文档提取技术指标并进行分类处理，支持研发和销售中的层级筛选，以实现与装备整机匹配的国产化连接器选择。其核心价值在于促进射频连接器的国产化进程，提升相关行业的自主创新能力。
