# InteractScience: Programmatic and Visually-Grounded Evaluation of Interactive Scientific Demonstration Code Generation

<p>
<a href='https://arxiv.org/abs/2510.09724'>
<img src='https://img.shields.io/badge/arXiv-2510.09724-b31b1b.svg'>
</a> &nbsp;&nbsp;&nbsp;

<a href="https://github.com/open-compass/InteractScience">
<img alt="GitHub" src="https://img.shields.io/badge/Github-InteractScience-000000?logo=github">
</a> &nbsp;&nbsp;&nbsp;

<a href="https://opensource.org/license/apache-2-0">
<img alt="Apache 2.0 License" src="https://img.shields.io/badge/License-Apache_2.0-4285f4.svg?logo=apache">
</a>
</p>

InteractScience is a benchmark specifically designed to evaluate the capability of large language models in generating interactive scientific demonstration code. This project provides a complete evaluation pipeline including model inference, automated testing, and multi-dimensional assessment.


## 📊 Dataset Description

### interactscience.jsonl
Main dataset file, each line contains a test sample:
- `id`: Unique identifier
- `question`: Detailed HTML implementation plan
- `lm_system_prompt`: Language model system prompt
- `vlm_system_prompt`: Vision-language model system prompt
- `image_path`: List of reference screenshot paths
- `snapshot_checklists`: Visual verification checklists

### Reference Screenshots
Located in `data/snapshots/` directory, naming format:
- `{task_id}_Snapshot-{number}.png`

## 🚀 Usage Tutorial

### 1. Environment Setup

First install Node.js and npm, then install the Playwright testing environment:

```bash
# Install project dependencies
npm install

# Install Playwright browsers
npx playwright install
```

### 2. Model Inference

Use the `run_generation.sh` script for model inference:

```bash
# Edit the model path and parameters in the script
vim run_generation.sh

# Run inference (requires model path configuration)
bash run_generation.sh
```

**Script Description:**
- Starts vLLM API server
- Calls `test_llm.py` for inference
- Results saved to `eval/` directory

### 3. Automated Testing

Use the `run_benchmark.sh` script for automated testing:

```bash
# Set the model name to test
export MODEL="your_model_name"

# Run tests
bash run_benchmark.sh
```

**Testing Process:**
1. Extract HTML code from inference results (`extract_and_save_code.py`)
2. Execute Program Functionality Testing (PFT) using `playwright_PFT.config.js`
3. Execute Visual Quality Testing (VQT) using `playwright_VQT.config.js`
4. Calculate CLIP similarity scores (`clip_score.py`)
5. Results saved to `results/` directory

### 4. VLM Scoring

Use `run_vlm_as_judge.sh` for VLM-as-Judge evaluation:

```bash
# Edit model and path configuration in the script
vim run_vlm_as_judge.sh

# Run VLM scoring
bash run_vlm_as_judge.sh
```

**Scoring Description:**
- Uses vision-language models to score generated results
- Compares reference screenshots with generated screenshots
- Evaluation based on predefined checklists

### 5. Results Analysis

Use `cal_metrics.py` and `cal_vlm_as_judege_score.py` to calculate final metrics:

```bash
python cal_metrics.py
python cal_vlm_as_judege_score.py
```

## 🧪 Test Types

### 1. Program Functionality Testing (PFT)
- Validates functional correctness of HTML code
- Checks interactive element behavior
- Tests JavaScript logic

### 2. Visual Quality Testing (VQT)
- Generates page screenshots
- Compares with reference screenshots
- Calculates perceptual similarity (CLIP scores)
- Calculates semantic correctness (VLM-judge scores)

## 🛠️ Core Scripts Description

### test_llm.py
Language model testing main program:
```bash
python test_llm.py \
--dataset_path data/interactscience.jsonl \
--prompt_type lm_system_prompt \
--dump_path eval/result.jsonl \
--model_path your_model_path \
--base_url http://localhost:8000/v1 \
--api_key EMPTY
```

### vlm_as_judge.py
VLM scoring main program:
```bash
python vlm_as_judge.py \
--reference_image_dir data/snapshots \
--generated_image_dir generated_images \
--checklist_file data/checklists.jsonl \
--output_path results/vlm_judge.jsonl \
--base_url your_api_endpoint \
--api_key your_api_key
```

## 📈 Evaluation Metrics

- **Program Functionality Test Pass Rate**: Percentage of PFT test cases passed
- **Visual Quality Score**: Visual similarity based on CLIP model
- **VLM Score**: Comprehensive score given by multimodal models

## Experiments

We have evaluated 30 state-of-the-art large language models on the InteractScience benchmark. The results are available in the `results/` directory.

| **Model** | **PFT Overall (%)** | **PFT Average (%)** | **PFT Perfect (%)** | **VQT Action (%)** | **VQT CLIP** | **VQT VLM-judge** |
|----------------------------|---------------------|---------------------|---------------------|--------------------|--------------|-------------------|
| **Closed-Source Large Language Models** |||||||
| GPT-5 | 39.47 | **37.61** | **16.08** | 89.66 | 71.95 | **57.02** |
| GPT-4.1 | 37.07 | 34.08 | 11.19 | 89.15 | 71.21 | 52.84 |
| GPT-4o | 28.27 | 27.09 | 5.59 | 85.93 | 67.11 | 42.45 |
| o3 | 34.93 | 32.09 | 13.99 | 89.83 | 72.24 | 52.82 |
| o4-mini | 37.33 | 34.90 | 13.29 | 88.64 | 71.79 | 51.90 |
| Gemini-2.5-Pro | 35.33 | 34.62 | 11.19 | 86.78 | 70.65 | 54.69 |
| Gemini-2.5-Flash | 31.60 | 31.07 | 10.49 | 86.95 | 69.59 | 49.34 |
| Claude-Sonnet-4-20250514 | **41.47** | 37.40 | 13.29 | 89.66 | 73.50 | 55.42 |
| Claude-Opus-4-20250514 | 40.27 | 36.34 | 11.19 | 89.32 | **73.22** | 54.93 |
| Claude-3.5-Sonnet | 33.33 | 31.45 | 9.79 | **90.17** | 72.32 | 49.43 |
| **Open-Source Large Language Models** |||||||
| DeepSeek-R1-0528 | **33.87** | **32.02** | 8.39 | 88.31 | 69.54 | 49.46 |
| DeepSeek-V3-0324 | 31.73 | 30.57 | 10.49 | 85.93 | 68.68 | 49.46 |
| Kimi-K2 | 31.60 | 31.22 | 9.79 | 87.29 | 70.11 | **50.04** |
| GLM-4.5 | 29.33 | 26.65 | 8.39 | 70.51 | 55.90 | 38.57 |
| Intern-S1 | 31.87 | 28.93 | 7.69 | 87.46 | 68.74 | 45.27 |
| gpt-oss-120b | 28.00 | 27.78 | 9.79 | **90.85** | **72.13** | 49.57 |
| gpt-oss-20b | 15.20 | 12.97 | 3.50 | 80.51 | 54.68 | 21.40 |
| Qwen3-235B-A22B-Instruct-2507 | 33.33 | 31.46 | **13.29** | 78.14 | 70.02 | 45.14 |
| Qwen3-32B | 27.20 | 24.09 | 5.59 | 87.46 | 66.46 | 39.69 |
| Qwen3-14B | 24.13 | 23.58 | 7.69 | 85.08 | 66.46 | 36.53 |
| Qwen3-8B | 20.00 | 18.85 | 4.20 | 81.53 | 64.13 | 34.67 |
| Qwen3-4B | 14.67 | 13.10 | 2.80 | 82.03 | 60.90 | 28.33 |
| Qwen3-1.7B | 6.53 | 6.22 | 1.40 | 75.76 | 59.65 | 20.33 |
| Qwen2.5-Coder-32B-Instruct | 27.20 | 25.10 | 7.69 | 84.58 | 51.67 | 38.51 |
| Qwen2.5-Coder-14B-Instruct | 22.53 | 20.61 | 4.90 | 85.42 | 64.47 | 35.72 |
| Qwen2.5-Coder-7B-Instruct | 12.40 | 10.51 | 0.70 | 82.37 | 65.17 | 26.97 |
| Qwen2.5-VL-72B-Instruct | 23.73 | 22.82 | 6.99 | 87.12 | 64.33 | 37.30 |
| Qwen2.5-VL-7B-Instruct | 7.47 | 6.72 | 0.70 | 70.00 | 49.49 | 20.41 |
| Llama-3.1-70B-Instruct | 18.67 | 18.04 | 4.90 | 88.64 | 59.56 | 33.36 |
| Llama-3.1-8B-Instruct | 11.33 | 10.16 | 3.50 | 80.00 | 65.42 | 22.75 |

### Comparison Across Difficulty Levels


### Comparison Across Disciplines


### Results on Multimodal LLMs with Reference Snapshots as Input


## Example Cases



## Citation
```
@article{InteractScience,
author = {Qiaosheng Chen and Yang Liu and Lei Li and Kai Chen and Qipeng Guo and Gong Cheng and Fei Yuan},
title = {InteractScience: Programmatic and Visually-Grounded Evaluation of Interactive Scientific Demonstration Code Generation},
journal = {arXiv preprint arXiv:2510.09724},
year = {2025}
}
```
