桥梁云链出图服务

基于桥梁上部结构标准图组成内容，对标准图进行结构化处理，搭建数字化商务运营及管理平台，实现此类结构标准图所囊括的跨径、角度以及任意宽度的图纸出图功能。出图范围包括《装配式预应力混凝土简支T梁标准图》、《装配式预应力混凝土箱型连续梁标准图》、《装配式预应力混凝土先简支后连续T梁标准图》、《钢板组合梁标准图》，共计63套标准图。

Based on the constituent contents of standard drawings for bridge superstructures, structured processing is performed on these standard drawings, and a digital business operation and management platform is established to realize the drawing generation function covering spans, angles and arbitrary widths included in such structural standard drawings. The scope of drawing generation includes Standard Drawings for Assembled Prestressed Concrete Simply Supported T-Beams, Standard Drawings for Assembled Prestressed Concrete Box-Section Continuous Beams, Standard Drawings for Assembled Prestressed Concrete T-Beams with Simply Supported-to-Continuous Transition, and Standard Drawings for Steel Plate Composite Beams, totaling 63 sets of standard drawings.

搜集汇总

背景与挑战

背景概述

该数据集提供桥梁上部结构标准图的结构化处理服务，包括多种类型的装配式预应力混凝土梁和钢板组合梁的标准图，共计63套。通过数字化平台实现跨径、角度及任意宽度的图纸出图功能。
