# Dataset card for Synth-APIGen-v0.1

This dataset has been created with [distilabel](https://distilabel.argilla.io/).

Pipeline script: [pipeline_apigen_train.py](https://huggingface.co/datasets/argilla/Synth-APIGen-v0.1/blob/main/pipeline_apigen_train.py).

## Dataset creation

It has been created with `distilabel==1.4.0` version.

This dataset is an implementation of [APIGen: Automated Pipeline for Generating Verifiable and Diverse Function-Calling Datasets](https://arxiv.org/abs/2406.18518) in `distilabel`,
generated from *synthetic* functions. The process can be summarized as follows:

- Generate (or in this case modify) python functions:

Using a simple pipeline, the functions obtained in [bigcode/self-oss-instruct-sc2-exec-filter-50k](https://huggingface.co/datasets/bigcode/self-oss-instruct-sc2-exec-filter-50k)
were modified to make them easily transformable to a json schema tool.

- Dataset: [argilla-warehouse/python-lib-tools-v0.1](https://huggingface.co/datasets/argilla-warehouse/python-lib-tools-v0.1)

- Prepare the seed tools for the `APIGen` pipeline:

We need a dataset with function names, their description and tool representation to be feed to our prompt, so the previous dataset hast to be transformed.
Also, a "golden source" can be used to feed examples as few-shot prompts: [Salesforce/xlam-function-calling-60k](https://huggingface.co/datasets/Salesforce/xlam-function-calling-60k).

- Dataset: [argilla-warehouse/python-seed-tools](https://huggingface.co/datasets/argilla-warehouse/python-seed-tools)

- Run the `APIGen` pipeline on the previous dataset:

The pipeline was run 2 times on the previous dataset, both to ensure diversity, and to try to obtain a higher number of functions:

- Dataset: [argilla-warehouse/synth-apigen-llama](https://huggingface.co/datasets/argilla-warehouse/synth-apigen-llama)
- Dataset: [argilla-warehouse/synth-qwen-llama](https://huggingface.co/datasets/argilla-warehouse/synth-apigen-qwen)

- Merge both datasets, deduplicate, and prepare for training

This is the final stage. The previous datasest have been merged, duplicates removed using a hash of the `query+answers` fields, near deduplication using
`MinHashDedup` from `distilabel`, and 6K examples "ill-formed" are generated to generate relevance detection data points, following the section B.3 of the paper
to showcase examples as in Berkeley Function-Calling Benchmark.

## Fine Tuning

The process can be seen [here](https://huggingface.co/argilla/Llama-3.2-1B-Instruct-APIGen-FC-v0.1#training-procedure). Basically, one needs to format the data for SFT
following a script like the one that can be found in the model card, which would yield a dataset like: [argilla-warehouse/apigen-synth-trl](https://huggingface.co/datasets/argilla-warehouse/apigen-synth-trl),
and run the training on top of it (in this case we've used [TRL](https://github.com/huggingface/trl), you can use the framework of your choice).

Take a look at [argilla/apigen-function-calling](https://huggingface.co/datasets/argilla/apigen-function-calling) for a merge of this dataset with the Salesforce one,
it just needs to be formatted to fine-tune a model on top of it.

## Example of use

The functions used to create this dataset are in this zipped folder [libs.zip](https://huggingface.co/datasets/argilla/Synth-APIGen-v0.1/blob/main/synth_lib_data/libs.zip).

If unzipped, it contains the 40K+ python files with the corresponding number of functions, which can be called like the following:

```python
from datasets import load_dataset

from distilabel.steps.tasks.apigen.utils import load_module_from_path

# Load the dataset
ds_apigen_synth = load_dataset("argilla/Synth-APIGen-v0.1", split="train")

# Select a row (from the valid ones, this dataset contains examples of queries that cannot be solved with the given information)
row = ds_apigen_synth.filter(lambda x: x["answers"].startswith("["))[1]

# {'func_name': 'sort_dict_by_values',
# 'func_desc': 'Returns a new dictionary sorted by the values in descending order, with keys in ascending order.',
# 'tools': '[{"type":"function","function":{"name":"int_to_bitwise_string","description":"Converts a positive integer to a bitwise string.","parameters":{"type":"object","properties":{"num":{"type":"integer","description":"The positive integer to convert."}},"required":["num"]}}},{"type":"function","function":{"name":"sort_dict_by_values","description":"Returns a new dictionary sorted by the values in descending order, with keys in ascending order.","parameters":{"type":"object","properties":{"dictionary":{"type":"object","additionalProperties":{},"description":"The dictionary to be sorted."}},"required":["dictionary"]}}}]',
# 'query': "You are organizing a book fair and have a list of books with their respective ratings. The list is as follows: {'The Great Gatsby': 4.5, '1984': 4.2, 'To Kill a Mockingbird': 4.7, 'Moby Dick': 3.8, 'Pride and Prejudice': 4.6}. Sort the books by their ratings in descending order, and if there are books with the same rating, sort them alphabetically by their titles.",
# 'answers': '[{"name": "sort_dict_by_values", "arguments": {"dictionary": {"The Great Gatsby": 4.5, "1984": 4.2, "To Kill a Mockingbird": 4.7, "Moby Dick": 3.8, "Pride and Prejudice": 4.6}}}]',
# 'model_name': 'Qwen/Qwen2.5-72B-Instruct',
# 'hash_id': '32fe6c61e9b2e94f6b0f18c2c6740c57be45cd20490949aa053f5689d1bd942f'}

# Extract the function name
function_name = row["func_name"]

# Load the function from the available python modules
toolbox = load_module_from_path(
str(Path(libpath) / f"{function_name}.py")
)

# Extract the function code
function = getattr(toolbox, function_name, None)

# And call it with the generated data from the model
function(*json.loads(row["answers"])[0]["arguments"].values())
# {'To Kill a Mockingbird': 4.7,
# 'Pride and Prejudice': 4.6,
# 'The Great Gatsby': 4.5,
# '1984': 4.2,
# 'Moby Dick': 3.8}
```

## Dataset content

From the original datasets, we gathered the following valid generations:

argilla-warehouse/synth-apigen-llama: 25727
argilla-warehouse/synth-apigen-qwen: 17678
Total: 43405

Following Section B.3 of the paper, we've added 6000 rows of incorrect function calls, making a total of 49402.
Additionally, instead of letting only the correct generated tool, the script generated the following distribution
of available tools:


### Fields description

- `func_name`: Name of the function
- `func_desc`: Description of the function behaviour.
- `tools`: Available tools to answer the query.
- `query`: Synthetic instruction generated from a user.
- `answers`: Arguments generated from the model that should be passed to the corresponding function to run and obtain the answer from.
- `model_name`: Model name used to obtain the row.
- `hash_id`: Hash generated from the query and answers to remove duplicates

Example:

```json
{
"func_name": "complex_to_polar",
"func_desc": "Converts a complex number to its polar coordinate representation.",
"tools": "[{\"type\":\"function\",\"function\":{\"name\":\"complex_to_polar\",\"description\":\"Converts a complex number to its polar coordinate representation.\",\"parameters\":{\"type\":\"object\",\"properties\":{\"complex_number\":{\"type\":\"object\",\"description\":\"A complex number in the form of `real + imaginary * 1j`.\"}},\"required\":[\"complex_number\"]}}}]",
"query": "I'd like to convert the complex number 3 + 4j and 1 - 2j to polar coordinates.",
"answers": "[{\"name\": \"complex_to_polar\", \"arguments\": {\"complex_number\": \"3 + 4j\"}}, {\"name\": \"complex_to_polar\", \"arguments\": {\"complex_number\": \"1 - 2j\"}}]",
"model_name": "meta-llama/Meta-Llama-3.1-70B-Instruct",
"hash_id": "f873783c04bbddd9d79f47287fa3b6705b3eaea0e5bc126fba91366f7b8b07e9",
}
```

## References

```
@article{liu2024apigen,
title={APIGen: Automated Pipeline for Generating Verifiable and Diverse Function-Calling Datasets},
author={Liu, Zuxin and Hoang, Thai and Zhang, Jianguo and Zhu, Ming and Lan, Tian and Kokane, Shirley and Tan, Juntao and Yao, Weiran and Liu, Zhiwei and Feng, Yihao and others},
journal={arXiv preprint arXiv:2406.18518},
year={2024}
}
```

<p align="left">
<a href="https://github.com/argilla-io/distilabel">
<img src="https://raw.githubusercontent.com/argilla-io/distilabel/main/docs/assets/distilabel-badge-light.png" alt="基于Distilabel构建" width="200" height="32"/>
</a>
</p>

# Synth-APIGen-v0.1 数据集卡片

本数据集基于distilabel构建，相关信息可访问[distilabel](https://distilabel.argilla.io/)。

流水线脚本：[pipeline_apigen_train.py](https://huggingface.co/datasets/argilla/Synth-APIGen-v0.1/blob/main/pipeline_apigen_train.py)。

## 数据集构建流程

本数据集基于distilabel 1.4.0版本构建。

本数据集是论文[APIGen：面向可验证且多样化函数调用数据集的自动化生成流水线](https://arxiv.org/abs/2406.18518)在distilabel中的实现，基于合成函数生成。构建流程可概括如下：

- 生成（或本案例中为修改）Python函数：

我们通过简易流水线，对[bigcode/self-oss-instruct-sc2-exec-filter-50k](https://huggingface.co/datasets/bigcode/self-oss-instruct-sc2-exec-filter-50k)中的函数进行修改，使其可轻松转换为JSON Schema格式的工具。

- 所用数据集：[argilla-warehouse/python-lib-tools-v0.1](https://huggingface.co/datasets/argilla-warehouse/python-lib-tools-v0.1)

- 为APIGen流水线准备种子工具集：

我们需要一份包含函数名称、功能描述与工具表示的数据集，用于送入提示词（prompt），因此需对前述数据集进行转换。此外，可使用「黄金源数据集」作为少样本（Few-shot）提示的示例来源：[Salesforce/xlam-function-calling-60k](https://huggingface.co/datasets/Salesforce/xlam-function-calling-60k)。

- 所用数据集：[argilla-warehouse/python-seed-tools](https://huggingface.co/datasets/argilla-warehouse/python-seed-tools)

- 在上述数据集上运行APIGen流水线：

我们在该数据集上两次运行APIGen流水线，以确保生成结果的多样性并获取更多函数样本：

- 所用数据集：[argilla-warehouse/synth-apigen-llama](https://huggingface.co/datasets/argilla-warehouse/synth-apigen-llama)
- 所用数据集：[argilla-warehouse/synth-qwen-llama](https://huggingface.co/datasets/argilla-warehouse/synth-apigen-qwen)

- 合并双数据集、去重并完成训练预处理

此为最终步骤：合并前述两个数据集，通过`query+answers`字段的哈希值移除重复样本，使用distilabel提供的`MinHashDedup`进行近似去重；同时参考论文B.3节，仿照伯克利函数调用基准测试（Berkeley Function-Calling Benchmark）生成6000条「格式错误」的样本，以构建相关性检测数据集。

## 微调流程

完整流程可参见[此处](https://huggingface.co/argilla/Llama-3.2-1B-Instruct-APIGen-FC-v0.1#training-procedure)。简而言之，需按照模型卡片中的脚本格式对数据进行监督微调（SFT），生成的数据集为[argilla-warehouse/apigen-synth-trl](https://huggingface.co/datasets/argilla-warehouse/apigen-synth-trl)，随后基于该数据集开展训练（本案例中使用了[TRL](https://github.com/huggingface/trl)框架，您也可自行选择适配的训练框架）。

您可访问[argilla/apigen-function-calling](https://huggingface.co/datasets/argilla/apigen-function-calling)查看本数据集与Salesforce原有数据集的合并版本，仅需对其进行格式转换即可用于模型微调。

## 使用示例

构建本数据集所用的函数存放在压缩文件夹[libs.zip](https://huggingface.co/datasets/argilla/Synth-APIGen-v0.1/blob/main/synth_lib_data/libs.zip)中。

解压后，该文件夹包含4万余个Python文件，内含对应数量的函数，调用方式如下：

python
from datasets import load_dataset

from distilabel.steps.tasks.apigen.utils import load_module_from_path

# Load the dataset
ds_apigen_synth = load_dataset("argilla/Synth-APIGen-v0.1", split="train")

# Select a row (from the valid ones, this dataset contains examples of queries that cannot be solved with the given information)
row = ds_apigen_synth.filter(lambda x: x["answers"].startswith("["))[1]

# {'func_name': 'sort_dict_by_values',
# 'func_desc': 'Returns a new dictionary sorted by the values in descending order, with keys in ascending order.',
# 'tools': '[{"type":"function","function":{"name":"int_to_bitwise_string","description":"Converts a positive integer to a bitwise string.","parameters":{"type":"object","properties":{"num":{"type":"integer","description":"The positive integer to convert."}},"required":["num"]}}},{"type":"function","function":{"name":"sort_dict_by_values","description":"Returns a new dictionary sorted by the values in descending order, with keys in ascending order.","parameters":{"type":"object","properties":{"dictionary":{"type":"object","additionalProperties":{},"description":"The dictionary to be sorted."}},"required":["dictionary"]}}}]",
# 'query': "You are organizing a book fair and have a list of books with their respective ratings. The list is as follows: {'The Great Gatsby': 4.5, '1984': 4.2, 'To Kill a Mockingbird': 4.7, 'Moby Dick': 3.8, 'Pride and Prejudice': 4.6}. Sort the books by their ratings in descending order, and if there are books with the same rating, sort them alphabetically by their titles.",
# 'answers': '[{"name": "sort_dict_by_values", "arguments": {"dictionary": {"The Great Gatsby": 4.5, "1984": 4.2, "To Kill a Mockingbird": 4.7, "Moby Dick": 3.8, "Pride and Prejudice": 4.6}}}]',
# 'model_name': 'Qwen/Qwen2.5-72B-Instruct',
# 'hash_id': '32fe6c61e9b2e94f6b0f18c2c6740c57be45cd20490949aa053f5689d1bd942f'}

# Extract the function name
function_name = row["func_name"]

# Load the function from the available python modules
toolbox = load_module_from_path(
str(Path(libpath) / f"{function_name}.py")
)

# Extract the function code
function = getattr(toolbox, function_name, None)

# And call it with the generated data from the model
function(*json.loads(row["answers"])[0]["arguments"].values())
# {'To Kill a Mockingbird': 4.7,
# 'Pride and Prejudice': 4.6,
# 'The Great Gatsby': 4.5,
# '1984': 4.2,
# 'Moby Dick': 3.8}

## 数据集内容

我们从原始数据集中整理得到以下有效生成样本：
argilla-warehouse/synth-apigen-llama: 25727
argilla-warehouse/synth-apigen-qwen: 17678
Total: 43405

参考论文B.3节，我们额外添加了6000条格式错误的函数调用样本，总样本量达到49402条。

此外，本脚本不仅生成了正确的工具调用样本，还生成了如下所示的可用工具分布情况：


### 字段说明

- `func_name`: 函数名称
- `func_desc`: 函数功能描述
- `tools`: 可用于响应用户查询的可用工具集
- `query`: 模拟用户生成的合成指令
- `answers`: 模型生成的参数，需传入对应函数以执行并获取最终结果
- `model_name`: 生成该条样本所用的模型名称
- `hash_id`: 基于query与answers字段生成的哈希值，用于去重

示例：

json
{
"func_name": "complex_to_polar",
"func_desc": "Converts a complex number to its polar coordinate representation.",
"tools": "[{"type":"function","function":{"name":"complex_to_polar","description":"Converts a complex number to its polar coordinate representation.","parameters":{"type":"object","properties":{"complex_number":{"type":"object","description":"A complex number in the form of `real + imaginary * 1j`."}},"required":["complex_number"]}}}]",
"query": "I'd like to convert the complex number 3 + 4j and 1 - 2j to polar coordinates.",
"answers": "[{"name": "complex_to_polar", "arguments": {"complex_number": "3 + 4j"}}, {"name": "complex_to_polar", "arguments": {"complex_number": "1 - 2j"}}]",
"model_name": "meta-llama/Meta-Llama-3.1-70B-Instruct",
"hash_id": "f873783c04bbddd9d79f47287fa3b6705b3eaea0e5bc126fba91366f7b8b07e9",
}

## 参考文献

@article{liu2024apigen,
title={APIGen: Automated Pipeline for Generating Verifiable and Diverse Function-Calling Datasets},
author={Liu, Zuxin and Hoang, Thai and Zhang, Jianguo and Zhu, Ming and Lan, Tian and Kokane, Shirley and Tan, Juntao and Yao, Weiran and Liu, Zhiwei and Feng, Yihao and others},
journal={arXiv preprint arXiv:2406.18518},
year={2024}
}
