面向拓扑结构优化的标准拓扑库数据集

本数据集主要用于验证课题一微波滤波器网络变换的解析方法的有效性。数据集内容涉及50个拓扑网络结构及其说明，静态和动态场景下50个网络拓扑的验证微波滤波器网络变换的解析方法的测试指标说明，包括回波损耗和传输零点位置。测试报告为第三方提供的验证课题一微波滤波器网络变换的解析方法有效性的测试报告，具体是在MATLAB环境下采用课题一的解析方法对该50个滤波器拓扑网络的耦合矩阵模型在静态与动态场景下的模型识别，且在静态下具有多解求解功能，在动态下具有在多解干扰下的指定解识别功能。

This dataset is primarily designed to validate the effectiveness of the analytical method for microwave filter network transformation proposed in Project 1. The dataset contains 50 topological network structures along with their corresponding descriptions, as well as test metric specifications for verifying the aforementioned analytical method using these 50 network topologies in both static and dynamic scenarios, including return loss and the location of transmission zeros. The accompanying test report is a third-party document that confirms the validity of the analytical method from Project 1. Specifically, the analytical method was implemented in the MATLAB environment to conduct model identification on the coupling matrix models of the 50 filter topological networks across static and dynamic scenarios. The method boasts multi-solution solving capability in static scenarios, and targeted solution identification functionality under multi-solution interference in dynamic scenarios.

搜集汇总

背景与挑战

背景概述

该数据集是一个标准拓扑库，主要用于验证微波滤波器网络变换解析方法的有效性。它包含50个拓扑网络结构及其在静态和动态场景下的测试指标，支持多解求解和指定解识别功能，数据格式多样，适用于电子通信和数学领域的拓扑优化研究。
