煤矸石自燃发生点位检测仪

本实用新型公开了一种煤矸石自燃发生点位检测仪，包括测温模块、传输模块及接收模块；测温模块包括插入煤矸石山多个测温点不同深度的热电偶测温探头；传输模块包括电表箱，电表箱内设有温度采集装置、预警装置及无线数据传输装置，并通过位于电表箱外的太阳能供电装置供电，热电偶测温探头分别通过补偿导线与位于电表箱内的温度采集装置连接，温度采集装置连接预警装置和无线数据传输装置，无线数据传输装置内安装内置手机卡并连接天线，通过GPS信号传输数据至接收模块；接收模块包括智能手机终端和计算机终端。温度采集装置不仅可以通过自身携带的显示屏现场显示温度，还可以通过无线传输装置将温度数据传输到计算机和手机等温度接收装置。

This utility model discloses a coal gangue spontaneous combustion point detector, which consists of a temperature measurement module, a transmission module and a receiving module. The temperature measurement module comprises thermocouple temperature measuring probes inserted into multiple temperature measurement points at different depths of the coal gangue pile. The transmission module includes an electric meter box, which is internally provided with a temperature acquisition device, a warning device and a wireless data transmission device, and is powered by a solar power supply device arranged outside the electric meter box. The thermocouple temperature measuring probes are respectively connected to the temperature acquisition device inside the electric meter box through compensating cables. The temperature acquisition device is connected with the warning device and the wireless data transmission device. A built-in SIM card is installed in the wireless data transmission device, which is connected to an antenna, and transmits data to the receiving module via GPS signals. The receiving module includes a smartphone terminal and a computer terminal. The temperature acquisition device can not only display the temperature on-site through its built-in display screen, but also transmit temperature data to temperature receiving devices such as computers and mobile phones via the wireless transmission device.

搜集汇总

背景与挑战

背景概述

该数据集涉及一种煤矸石自燃发生点位检测仪，它通过热电偶测温探头、无线数据传输装置等模块，实现对煤矸石山自燃点位的温度监测和数据传输。该仪器属于'西北干旱荒漠区煤炭基地生态安全保障技术'项目的一部分，旨在提供生态安全相关的技术报告。
