# Adapting Multimodal Large Language Models to Domains via Post-Training (EMNLP 2025)

This repos contains the **biomedicine visual instructions for post-training MLLMs** in our paper: [On Domain-Specific Post-Training for Multimodal Large Language Models](https://huggingface.co/papers/2411.19930).

The main project page is: [Adapt-MLLM-to-Domains](https://huggingface.co/AdaptLLM/Adapt-MLLM-to-Domains)

## Data Information
Using our [visual instruction synthesizer](https://huggingface.co/AdaptLLM/visual-instruction-synthesizer), we generate visual instruction tasks based on the image-caption pairs from [PubMedVision](https://huggingface.co/datasets/FreedomIntelligence/PubMedVision) (referred to as `PMC_refined` in our paper). These synthetic tasks, combined with the original image captioning tasks, are used to train general MLLMs through a single-stage post-training process.

- **image_caption_pairs.json**: Derived from [PubMedVision_Alignment_VQA](https://huggingface.co/datasets/FreedomIntelligence/PubMedVision/blob/main/PubMedVision_Alignment_VQA.json) in PubMedVision, we include only single-image examples, resulting in 500K image-caption pairs.
- **synthetic_visual_tasks.json**: Synthesized based on the aforementioned image-caption pairs, containing 144K synthetic instruction-response pairs after applying our consistency-based data filter.
- **image_caption_and_synthetic_task.json**: This dataset is used to reproduce our `single-stage domain-specific post-training`, containing both image-captioning tasks and synthetic visual-instruction tasks, totaling 500K examples (equal to the number of image-caption pairs).

## To Download the Data
1. Set up dependencies:
```bash
pip install "huggingface_hub[cli]"
```

2. Download text data:
```bash
REPO="AdaptLLM/biomed-visual-instructions"

# The local directory where you intend to save the files
LOCAL_DIR="./biomed-visual-instructions"

# Choose from ["image_caption_and_synthetic_task.json", "image_caption_pairs.json", "synthetic_visual_tasks.json"]
FILE="image_caption_and_synthetic_task.json" # This is used for reproducing AdaMLLM in our paper.

huggingface-cli download --resume-download ${REPO} ${FILE} --local-dir ${LOCAL_DIR} --repo-type dataset
```

3. Download image data:
```bash
REPO="FreedomIntelligence/PubMedVision"

huggingface-cli download --resume-download ${REPO} --local-dir ${LOCAL_DIR} --repo-type dataset --include "images_*.zip"
```

4. Unzip the downloaded images:
```bash
cd ${LOCAL_DIR}

for ((i=0; i<20; i++))
do
unzip -j images_$i.zip -d images/ & # Wait patiently, it takes a while...
done
```

## To reproduce the data

We have included detailed scripts to reproduce the data in [Synthesis.md](https://github.com/bigai-ai/QA-Synthesizer/blob/main/docs/Synthesis.md).

## To train MLLMs using the data

Our training data can be easily used to train MLLMs based on the `Llava` repository or the `LLaMA Factory` repository. Please refer to the [Post-Train Guide](https://github.com/bigai-ai/QA-Synthesizer/blob/main/docs/Post_Train.md).

## Citation
If you find our work helpful, please cite us.

[Adapt MLLM to Domains](https://huggingface.co/papers/2411.19930) (EMNLP 2025 Findings)
```bibtex
@article{adamllm,
title={On Domain-Adaptive Post-Training for Multimodal Large Language Models},
author={Cheng, Daixuan and Huang, Shaohan and Zhu, Ziyu and Zhang, Xintong and Zhao, Wayne Xin and Luan, Zhongzhi and Dai, Bo and Zhang, Zhenliang},
journal={arXiv preprint arXiv:2411.19930},
year={2024}
}
```

[Adapt LLM to Domains](https://huggingface.co/papers/2309.09530) (ICLR 2024)
```bibtex
@inproceedings{
adaptllm,
title={Adapting Large Language Models via Reading Comprehension},
author={Daixuan Cheng and Shaohan Huang and Furu Wei},
booktitle={The Twelfth International Conference on Learning Representations},
year={2024},
url={https://openreview.net/forum?id=y886UXPEZ0}
}
```

# 基于后训练的多模态大语言模型领域适配（EMNLP 2025）

本仓库包含我们的论文《On Domain-Specific Post-Training for Multimodal Large Language Models》（https://huggingface.co/papers/2411.19930）中用于多模态大语言模型（Multimodal Large Language Model, MLLM）后训练的生物医学视觉指令集。

项目主页为：[Adapt-MLLM-to-Domains](https://huggingface.co/AdaptLLM/Adapt-MLLM-to-Domains)

## 数据集详情

我们借助[视觉指令合成器（visual instruction synthesizer）](https://huggingface.co/AdaptLLM/visual-instruction-synthesizer)，基于来自[PubMedVision](https://huggingface.co/datasets/FreedomIntelligence/PubMedVision)的图像-文本对（本文中记为`PMC_refined`）生成视觉指令任务。将这些合成任务与原始图像字幕任务相结合，即可通过单阶段后训练流程训练通用多模态大语言模型。

- **image_caption_pairs.json**：源自PubMedVision数据集内的[PubMedVision_Alignment_VQA](https://huggingface.co/datasets/FreedomIntelligence/PubMedVision/blob/main/PubMedVision_Alignment_VQA.json)，仅保留单图像样本，最终得到50万条图像-文本对。
- **synthetic_visual_tasks.json**：基于前述图像-文本对合成所得，经基于一致性的数据过滤后，共包含14.4万条合成指令-回复对。
- **image_caption_and_synthetic_task.json**：该数据集用于复现我们的`单阶段特定领域后训练`流程，同时包含图像字幕任务与合成视觉指令任务，总计50万条样本（与图像-文本对的数量一致）。

## 数据下载

1. 配置依赖环境：
bash
pip install "huggingface_hub[cli]"

2. 下载文本数据：
bash
REPO="AdaptLLM/biomed-visual-instructions"

# 用于存储文件的本地目录
LOCAL_DIR="./biomed-visual-instructions"

# 可选文件列表：["image_caption_and_synthetic_task.json", "image_caption_pairs.json", "synthetic_visual_tasks.json"]
FILE="image_caption_and_synthetic_task.json" # 本文件用于复现本文中的AdaMLLM模型。

huggingface-cli download --resume-download ${REPO} ${FILE} --local-dir ${LOCAL_DIR} --repo-type dataset

3. 下载图像数据：
bash
REPO="FreedomIntelligence/PubMedVision"

huggingface-cli download --resume-download ${REPO} --local-dir ${LOCAL_DIR} --repo-type dataset --include "images_*.zip"

4. 解压下载的图像文件：
bash
cd ${LOCAL_DIR}

for ((i=0; i<20; i++))
do
unzip -j images_$i.zip -d images/ &# 请耐心等待，解压过程将耗时片刻

done

## 数据复现

我们已在[Synthesis.md](https://github.com/bigai-ai/QA-Synthesizer/blob/main/docs/Synthesis.md)中提供了复现该数据集的详细脚本。

## 基于该数据集训练多模态大语言模型

我们的训练数据可直接用于基于`Llava`仓库或`LLaMA Factory`仓库的多模态大语言模型训练，请参考[后训练指南（Post-Train Guide）](https://github.com/bigai-ai/QA-Synthesizer/blob/main/docs/Post_Train.md)。

## 引用

若您的工作受益于本数据集，请引用我们的论文。

[Adapt MLLM to Domains](https://huggingface.co/papers/2411.19930)（EMNLP 2025 发现论文）
bibtex
@article{adamllm,
title={On Domain-Adaptive Post-Training for Multimodal Large Language Models},
author={Cheng, Daixuan and Huang, Shaohan and Zhu, Ziyu and Zhang, Xintong and Zhao, Wayne Xin and Luan, Zhongzhi and Dai, Bo and Zhang, Zhenliang},
journal={arXiv preprint arXiv:2411.19930},
year={2024}
}

[Adapt LLM to Domains](https://huggingface.co/papers/2309.09530)（ICLR 2024）
bibtex
@inproceedings{
adaptllm,
title={Adapting Large Language Models via Reading Comprehension},
author={Daixuan Cheng and Shaohan Huang and Furu Wei},
booktitle={The Twelfth International Conference on Learning Representations},
year={2024},
url={https://openreview.net/forum?id=y886UXPEZ0}
}
