Benchmark-Dataset FAN-01: Low pressure Axial Fan in a short Duct

The case consists of a generic axial fan for industrial applications. Provided measurement data include instationary pressure probes in the rotor's tip gap, distributions of velocity and turbulent kinetic energy gained by laser Doppler anemometry, as well as acoustic results gained by microphones and beamforming. A detailed description of the dataset with references can be found in the PDF-File. The rotor geometry is available as IGS or Parasolid file. The measurement data is available, including the ones (LDA-data, pressure probes, acoustic microphones, üerformance) listed in the PDF description file. Citation of the fan and the data: Zenger, Florian, et al. A benchmark case for aerodynamics and aeroacoustics of a low pressure axial fan. No. 2016-01-1805. SAE Technical Paper, 2016. Citation of the microphone array measurements: Krömer, Florian J. Sound emission of low-pressure axial fans under distorted inflow conditions. FAU University Press, 2018. Citation of the python scripts: Junger, Clemens. Computational aeroacoustics for the characterization of noise sources in rotating systems. Diss. Technische Universität Wien, 2019. Related work and existing publications: Schoder, Stefan, Clemens Junger, and Manfred Kaltenbacher. "Computational aeroacoustics of the EAA benchmark case of an axial fan." Acta Acustica 4.5 (2020): 22. https://doi.org/10.1051/aacus/2020021 Schoder, Stefan, and Felix Czwielong. "Dataset fan-01: Revisiting the EAA benchmark for a low-pressure axial fan." arXiv preprint arXiv:2211.12014 (2022). https://doi.org/10.48550/arXiv.2211.12014 Kaltenbacher, Manfred, and Stefan Schoder. "EAA Benchmark for an axial fan." e-Forum Acusticum 2020. 2020. https://hal.science/hal-03221387/document Tieghi, Lorenzo, et al. "Machine-learning clustering methods applied to detection of noise sources in low-speed axial fan." Journal of Engineering for Gas Turbines and Power 145.3 (2023): 031020. https://doi.org/10.1115/1.4055417 Antoniou, E., Romani, G., Jantzen, A., Czwielong, F., & Schoder, S. (2023). Numerical flow noise simulation of an axial fan with a Lattice-Boltzmann solver. Acta Acustica, 7, 65. https://doi.org/10.1051/aacus/2023060 Data curation and Questions about the Dataset Data curated by Stefan Schoder, any questions related to the dataset to [e-mail].

搜集汇总

背景与挑战

背景概述

该数据集是一个用于工业应用的通用低压轴流风扇基准测试数据集，包含转子尖端间隙的非稳态压力探头测量、激光多普勒测速仪获得的流速和湍流动能分布，以及麦克风和波束成形技术采集的声学结果。数据集提供了详细的测量数据、几何模型文件和Python脚本，旨在支持气动声学研究和计算验证，由多所大学合作创建并开放共享。
