PAM4芯片接收SNDR数据

接收SNDR是PAM4芯片的核心指标。信号源接收码型为SSPRQ的信号，将信号输入PAM4芯片接收端，配置PAM4芯片内部的ADC来采集数据，将采集的数据输出PAM4芯片至PC，通过PC内置的应用软件对数据进行计算，获得接收SNDR值，判断其是否满足指标要求。Received Signal-to-Noise and Distortion Ratio (SNDR) is a core performance indicator for PAM4 chips. The test procedure is as follows: First, the signal source receives a signal encoded with the SSPRQ pattern and inputs it to the receiver port of the PAM4 chip. Next, configure the internal analog-to-digital converter (ADC) of the PAM4 chip to collect the input data, then transfer the collected data from the PAM4 chip to a personal computer (PC). Finally, use the built-in application software on the PC to perform calculations on the collected data to derive the received SNDR value, and verify whether the value meets the predefined indicator requirements.

搜集汇总

背景与挑战

背景概述

该数据集聚焦于PAM4芯片接收端的SNDR性能测试，通过SSPRQ信号输入、ADC采集和软件计算获取关键指标值，用于评估芯片是否符合要求。它属于集成电路技术领域，数据量较小（1.17MB），源自国家重点研发计划项目，旨在支持5G光传输芯片的研发与验证。
