Synthetic Aperture Radar Microwave Vision 3D Imaging Dataset-3.0

This dataset is version 3.0 of the SAR microwave vision 3D imaging dataset (SARMV3D-3.0). The data set consists of three subsets: 1) Small UAV-borne full-polarization array-InSAR data subset; 2) Electromagnetic scattering data subset for typical scattering mechanisms; 3) Airborne array-InSAR data subset for typical targets.The first set consists of the UAV-borne full-polarization array-InSAR data of a building taken from 8 different directions, captured by the microwave vision three-dimensional SAR system (MV3DSAR) in Suzhou in October 2022. It also contains laser point cloud data and optical oblique photography data acquired in the same period. This subset can be used in the study of SAR 3D imaging based on microwave vision.The second subset contains the UAV-borne full-polarization array-InSAR data captured by the MV3DSAR taken from one direction in Suzhou in October 2022. We placed SLICY modified models, ship models and aircplane models in the experiment site. These three models are composed of dihedral angle, sphere, trihedral angle, paraboloid, cylinder, and other scatterers. It can be used for the study of electromagnetic scattering mechanism.The third subset contains 14-channel airborne array In-SAR data of cars, ships and oil tanks. This subset can be used in the research of SAR 3D imaging based on microwave vision.To use the data set please quote:[1] QIU Xiaolan, LUO Yitong, CHENG Yao, LIN Bei, YANG Hong, SAR Microwave Vision 3D imaging Dataset 3.0[OL]. Journal of Radars, 2024. https://radars.ac.cn/web/data/getData?newsColumnId=2f2748db-10ef-4ad0-bcc4-f087ce59b6f8&pageType=en[2] QIU Xiaolan, JIAO Zekun, YANG Zhenli, et al. Key technology and preliminary progress of microwave vision 3D SAR experimental system[J]. Journal of Radars, 2022, 11(1): 1–19. doi: 10.12000/JR22027.[3] QIU Xiaolan, JIAO Zekun, PENG Lingxiao, et al. SARMV3D-1.0: Synthetic Aperture Radar Microwave Vision 3D Imaging Dataset[J]. Journal of Radars, 2021, 10(4): 485–498. doi: 10.12000/JR21112.Dataset Download Address: https://radars.ac.cn/web/data/getData?dataType=SARMV3DVersion1.0: https://radars.ac.cn/web/data/getData?newsColumnId=aac4fc85-5950-432a-8ca2-bf14608d4461Version 2.0: https://radars.ac.cn/web/data/getData?newsColumnId=f9286c6f-a287-4e5f-be76-105b07677c3c

本数据集为SAR微波视觉三维成像数据集（SAR Microwave Vision 3D Imaging Dataset）3.0版本（SARMV3D-3.0）。数据集包含三个子数据集：1）小型无人机载全极化阵列干涉合成孔径雷达（InSAR）数据子集；2）典型散射机制电磁散射数据子集；3）面向典型目标的机载阵列干涉合成孔径雷达数据子集。

第一种子集包含2022年10月于苏州由微波视觉三维SAR系统（MV3DSAR）采集的、从8个不同方位获取的某建筑的无人机载全极化阵列干涉合成孔径雷达数据，同时包含同期采集的激光点云数据与光学倾斜摄影数据。该子集可用于基于微波视觉的SAR三维成像研究。

第二种子集包含2022年10月于苏州由MV3DSAR从单一方位获取的无人机载全极化阵列干涉合成孔径雷达数据。本次实验场地中布设了SLICY改进型模型、船舶模型与飞机模型，这三类模型由二面角、球体、三面角、抛物面、圆柱体等散射体构成。该子集可用于电磁散射机制相关研究。

第三种子集包含面向汽车、船舶与油罐的14通道机载阵列干涉合成孔径雷达数据，可用于基于微波视觉的SAR三维成像研究。

使用本数据集请引用以下文献：
[1] 邱晓兰, 罗亦彤, 程遥, 林贝, 杨洪. SAR微波视觉三维成像数据集3.0[OL]. 雷达学报, 2024. https://radars.ac.cn/web/data/getData?newsColumnId=2f2748db-10ef-4ad0-bcc4-f087ce59b6f8&pageType=en
[2] 邱晓兰, 焦泽坤, 杨正立, 等. 微波视觉三维SAR实验系统关键技术与初步进展[J]. 雷达学报, 2022, 11(1): 1–19. doi: 10.12000/JR22027.
[3] 邱晓兰, 焦泽坤, 彭凌霄, 等. SARMV3D-1.0: 合成孔径雷达微波视觉三维成像数据集[J]. 雷达学报, 2021, 10(4): 485–498. doi: 10.12000/JR21112.

数据集下载地址：
版本1.0：https://radars.ac.cn/web/data/getData?newsColumnId=aac4fc85-5950-432a-8ca2-bf14608d4461
版本2.0：https://radars.ac.cn/web/data/getData?newsColumnId=f9286c6f-a287-4e5f-be76-105b07677c3c

搜集汇总

背景与挑战

背景概述

该数据集是SAR微波视觉3D成像数据集的3.0版本，包含三个子集，分别用于SAR 3D成像和电磁散射机制的研究。数据集由中国科学院和苏州空天信息研究院的研究人员发布，总数据量为62.98 GB。
