Zemax (optical design) files of microscope objectives, tube lenses, and Fourier imaging setups

This fileset contains Zemax files related to the manuscript entitled “Comparative analysis of imaging configurations and objectives for Fourier microscopy” by Jonathan A. Kurvits, Mingming Jiang, and Rashid Zia. Specifically, it includes multi-configuration Zemax files that allow for the comparison of different Fourier microscopy imaging configurations as well as Zemax lens files and lens catalogs for microscope objectives and tube lenses, as inferred from the following published patents: 1) U.S. Patent # 5,517,360; assignee: Olympus; objective description: 60x, 1.4 NA Plan Apo. 2) U.S. Patent # 5,659,425; assignee: Olympus; objective description: 100x, 1.65 NA Apo. 3) U.S. Patent # 6,504,563; assignee: Zeiss; objective description: 100x, 1.45 NA TIRF. 4) U.S. Patent # 6,519,092; assignee: Nikon; objective description: 60x, 1.4 NA Plan Apo. 5) U.S. Patent # 6,519,092; assignee: Nikon; objective description: 100x, 1.4 NA Plan Apo. 6) U.S. Patent # 7,046,451; assignee: Nikon; objective description: 60x, 1.5 NA TIRF (modeled as 1.49 NA to match possible commercial realization). 7) U.S. Patent # 7,046,451; assignee: Nikon; objective description: 100x, 1.5 NA TIRF (modeled as 1.49 NA to match possible commercial realization). 8) U.S. Patent # 7,889,433; assignee: Nikon; objective description: 60x, 1.25 water immersion. <strong>Update</strong> <strong>(9/14/2015, Version 2, filenames annotated with "_v2" suffix):</strong> For all objectives files and the objective catalog, the immersion oil layer semi-diameter has been changed to float so as to prevent unrealistic vignetting that may otherwise occur. Additionally, for all multiconfiguration files, the "before image plane" configuration has been modified. Specifically, the position of the Bertrand Lens has been modified so that it correctly images the BFP image onto the real image plane. In all cases, this required a shift in the position of the Bertrand Lens of ~1cm further from the tube lens. <strong>Update (10/19/2015, Description only):</strong> The related paper on “Comparative analysis of imaging configurations and objectives for Fourier microscopy” by Jonathan A. Kurvits, Mingming Jiang, and Rashid Zia has been published in the Journal of the Optical Society of America A [J. Opt. Soc. Am. A 32, 2082-2092 (2015)]. This paper provides a detailed description of how these Zemax models were produced and analyzed. If you use the Zemax models provided here, we would appreciate it if you could cite this paper as well as the figshare fileset. Here is a link to the paper: http://dx.doi.org/10.1364/JOSAA.32.002082

本文件集包含与Jonathan A. Kurvits、Mingming Jiang及Rashid Zia所撰写的题为"傅里叶显微镜成像配置与物镜对比分析"的手稿相关的Zemax文件。具体而言，本文件集包含支持多种傅里叶显微镜成像配置对比的多配置Zemax文件，以及基于下述已发表专利推导得到的显微镜物镜与管镜的Zemax镜头文件和镜头库：
1. 美国专利第5,517,360号，受让方：奥林巴斯（Olympus），物镜参数：60倍、数值孔径（Numerical Aperture，NA）1.4的Plan Apo物镜
2. 美国专利第5,659,425号，受让方：奥林巴斯，物镜参数：100倍、NA 1.65的Apo物镜
3. 美国专利第6,504,563号，受让方：蔡司（Zeiss），物镜参数：100倍、NA 1.45的全内反射荧光（Total Internal Reflection Fluorescence，TIRF）物镜
4. 美国专利第6,519,092号，受让方：尼康（Nikon），物镜参数：60倍、NA 1.4的Plan Apo物镜
5. 美国专利第6,519,092号，受让方：尼康，物镜参数：100倍、NA 1.4的Plan Apo物镜
6. 美国专利第7,046,451号，受让方：尼康，物镜参数：60倍、NA 1.5的TIRF物镜（为匹配实际商用规格，建模为NA 1.49）
7. 美国专利第7,046,451号，受让方：尼康，物镜参数：100倍、NA 1.5的TIRF物镜（为匹配实际商用规格，建模为NA 1.49）
8. 美国专利第7,889,433号，受让方：尼康，物镜参数：60倍、NA 1.25的水浸物镜

<strong>更新（2015年9月14日，版本2，文件名标注"_v2"后缀）</strong>：针对所有物镜文件及物镜库，已将浸油层半直径设为浮点型参数，以避免可能出现的非真实渐晕现象。此外，所有多配置文件的"像面前置"配置已完成修改：具体而言，已调整伯特兰透镜（Bertrand Lens）的位置，使其可将后焦面（Back Focal Plane，BFP）图像正确成像至实像面。所有调整均需将伯特兰透镜相对于管镜的位置外移约1厘米。

<strong>更新（2015年10月19日，仅更新说明文本）</strong>：上述《傅里叶显微镜成像配置与物镜对比分析》相关论文已发表于《美国光学学会A辑期刊》[J. Opt. Soc. Am. A 32, 2082-2092 (2015)]。该论文详细阐述了本Zemax模型的构建与分析方法。若您使用此处提供的Zemax模型，恳请您同时引用该论文与figshare文件集。论文链接：http://dx.doi.org/10.1364/JOSAA.32.002082
