DOUBLE END TENONER

[Task] Provide a double-ended tenoner that enables sizing with high precision by passing the workpiece through the machining spindle once， enabling actual machining， and efficiently obtaining a plate of parallel quadrilateral when viewed from a plane. . [Solution means] The double-ended tenoner (1) is provided with at least the base body (2) and two left and right columns (3， 4) arranged in parallel， and the columns (3， 4) forward the workpiece Caterpillar chain (5， 6) to be conveyed by the method， a plurality of processing spindles (S1 to S5) for processing the workpiece to be conveyed， and caterpillar chain drive motors (7， 8)， and two columns (3， Any of 4) moves in the front-rear direction with respect to the base body 2， and can be held at an arbitrary position.

搜集汇总

背景与挑战

背景概述

该数据集涉及双端榫机，其功能是通过一次加工实现工件的高精度尺寸调整，并获得平面上的平行四边形板材。数据集属于植物学领域，以文本格式提供，数据时间为2020年，关键词为JP201944059A。
