Dataset on Helically Coiled Oscillating Heat Pipe (HCOHP)
收藏资源简介：
This dataset contains raw primary temperature data obtained from the three HCOHPs charged with ethanol, methanol, and deionized water respectively and tested in the laboratory using three different heat inputs. The maximum heat input element temperatures were 100°C, 125°C and 192°C, for test Run 1, 2 and 3, respectively. The temperature data were obtained from three Omega K-type thermocouples attached to each condenser and evaporator of the HCOHP respectively, two attached to the adiabatic sections, and two attached to the inner and outer surfaces of the cylindrical copper vessel for the heat transfer. The other dataset is derived from the average temperatures from the raw primary temperature data. Here, relevant equations for the determination of the heat flux, power input, thermal contact resistance and overall thermal resistance was used. The data are presented on six separate Excel files. The first three files are captioned HCOHP Primary Data – Run 1, HCOHP Primary Data – Run 2, and HCOHP Primary Data – Run 3 representing raw primary temperature data for the three HCOHPs for each test run. The second three Excel files are captioned HCOHP Derived Data – Run 1, HCOHP Derived Data – Run 2, and HCOHP Derived Data – Run 3 represent the derived data obtained from the average raw primary temperature data for each test run. In the Excel files EOHP, MOHP and WOHP represents the ethanol charged HCOHP, methanol charged HCOHP and deionized water charged HCOHP, respectively.
本数据集包含三台分别充装乙醇、甲醇与去离子水的环路热管（HCOHP），在实验室中采用三种不同热输入工况下测试得到的未处理原始温度数据。三次测试（Run 1、Run 2、Run 3）对应的最大热输入元件温度分别为100℃、125℃与192℃。 本次采集的温度数据来自：分别安装在各台HCOHP冷凝器与蒸发器上的三支欧米茄（Omega）K型热电偶、安装于绝热段的两支热电偶，以及安装在换热用圆柱形铜容器内外表面的两支热电偶。 另一组数据集由上述未处理原始温度数据的平均温度值衍生得到，本数据集采用了用于计算热通量、输入功率、接触热阻与总热阻的相关公式。 所有数据均存储于六个独立的Excel文件中：前三个文件的标题分别为「HCOHP 原始数据——测试 Run 1」、「HCOHP 原始数据——测试 Run 2」与「HCOHP 原始数据——测试 Run 3」，分别对应各次测试中三台HCOHP的未处理原始温度数据；后三个Excel文件的标题分别为「HCOHP 衍生数据——测试 Run 1」、「HCOHP 衍生数据——测试 Run 2」与「HCOHP 衍生数据——测试 Run 3」，分别对应各次测试中由原始温度数据平均值衍生得到的数据集。在各Excel文件中，EOHP、MOHP与WOHP分别代表充装乙醇的HCOHP、充装甲醇的HCOHP与充装去离子水的HCOHP。
