基于X 切薄膜铌酸锂的90 度弯曲波导相关仿真数据

本数据集面向X切薄膜铌酸锂中的各向异性问题，通过数值计算软件，对不同参数波导TE和TM模等效折射率的影响（包括：波导宽度、平板厚度和波导总厚的比例、波导总厚度、波导侧壁刻蚀角度、波导倾斜角度、包层折射率）、弯曲波导模式转换效率等进行的数值模拟，并得出相关曲线。

This dataset focuses on the anisotropy issue in X-cut thin-film lithium niobate. It conducted numerical simulations via numerical calculation software to analyze the effects of various waveguide parameters (including waveguide width, the ratio of slab thickness to total waveguide thickness, total waveguide thickness, etching angle of waveguide sidewalls, waveguide tilt angle, and cladding refractive index) on the effective refractive indices of TE and TM modes, as well as the mode conversion efficiency of bent waveguides, and derived relevant characteristic curves.

搜集汇总

背景与挑战

背景概述

该数据集聚焦于X切薄膜铌酸锂的各向异性特性，通过数值模拟研究了波导宽度、厚度、刻蚀角度等参数对TE和TM模等效折射率的影响，并评估了弯曲波导的模式转换效率。数据以曲线形式呈现，适用于通信传输技术领域的相关分析。
