北山节理裂隙及渗水病害调查数据

通过地质勘察，借助地质罗盘、皮尺、塞尺等工具，在重庆大足北山石刻及周边区域共调查节理裂隙622条，详细记录了裂隙的倾向、倾角、迹长、隙宽、间距、充填等数据，与此同时，在北山石刻第1~290号窟共调查渗水病害49处，详细记录了渗水点的位置、临空面倾角、临空面倾向、临空面走向、渗水类型、过水面积形状、渗水点底高度、顶高度及过水断面长度、高度等数据，数据量6.89M。A geological investigation was carried out in the Dazu North Mountain Stone Carvings and its surrounding regions in Chongqing, using tools including geological compass, steel tape measure, feeler gauge and other relevant instruments. A total of 622 joints and fractures were investigated, with detailed data such as their dip direction, dip angle, trace length, joint aperture, spacing, and filling status recorded. Meanwhile, 49 water seepage defects were surveyed in Cave Nos. 1 to 290 of the North Mountain Stone Carvings, and comprehensive data including the location of each seepage point, dip angle, dip direction and strike of the free face, seepage type, shape of the water flow area, bottom and top heights of the seepage point, as well as the length and height of the water flow section were collected. The total data volume amounts to 6.89 MB.

搜集汇总

背景与挑战

背景概述

该数据集针对重庆大足北山石刻及周边区域，通过地质勘察工具调查了622条节理裂隙和49处渗水病害，详细记录了裂隙倾向、倾角、迹长等参数以及渗水点位置、类型等数据，数据量约为6.9MB。
