11-bus and 240-bus radial distribution feeder datasets for power flow calculation

This dataset includes the system data and equivalent Distributed Energy Resource (DER) allocations for two test cases: an 11-bus system and a 240-bus radial test feeder. The 11-bus system data is based on the CIGRE Technical Report "Benchmark system for network integration of renewable and distributed energy resources," 575, 2014. The 240-bus is based on the test system described in the paper titled "A time-series distribution test system based on real utility data" by F. Bu, Y. Yuan, Z. Wang, K. Dehghanpour, and A. Kimber, 2019 NAPS Conference, 2019. This dataset aims to help researchers model radial distribution systems and test methodologies for integrating and managing DERs to enhance steady-state analyses.

搜集汇总

背景与挑战

背景概述

该数据集包含11总线和240总线径向配电馈线的测试案例，专为电力流计算设计，用于建模和分析径向配电系统。数据集提供了分布式能源资源（DER）分配、分支参数、总线数据和天气信息等详细表格，支持稳态分析研究。基于CIGRE技术报告和实际电力公司数据，它旨在帮助研究人员测试DER集成和管理方法，以增强电力系统性能。
