I. Construction Objectives

The goal is to achieve "Digital Mine Management", integrate mine spatial information expression and real-time production data management, realize true 3D simulation integrating underground and surface mining areas, enhance the visualization of mine environmental data, improve the understanding and application scenarios of mine geological data, improve the utilization efficiency of mine production information and spatial analysis capability, and realize the digitalization of resources and mining environment, as well as the scientization of production management and decision-making.

For the integrated management scheme of multi-source heterogeneous massive data in smart mines, under a unified spatio-temporal framework, comprehensively collect, organize and process basic mine data and production data, perform centralized or distributed management in accordance with unified classification standards and data organization formats, and build a mine spatial data warehouse that can be shared and utilized within the enterprise. This achieves unified management and shared utilization of exploration spatial information data and real-time mine production data. The established "Mine Data Center" provides a solid and efficient data foundation for the entire "Smart Mine".

II. System Framework

1. Production and Perception Layer: Use Internet of Things (IoT) technology to comprehensively perceive the status of underground environments, personnel, machinery, etc., and monitor equipment.

2. Mine Data Warehouse Layer: Provide data access and exchange as well as data processing, realize the integration and fusion of multi-source heterogeneous perception data, break the barrier between perception data and intelligent applications based on perception data, realize the access to various perception data downward, and provide data support for final applications, decision-making and display upward.

3. Application, Decision-making and Display Layer: Realize the integration of automation and informatization for application systems such as geological guarantee, safety guarantee, production execution and emergency rescue. At the same time, meet the needs of different mine users through display methods such as leadership cockpit, mine comprehensive portal, and mine comprehensive early warning. (Illustration is provided in the main text)

III. Construction Contents

3.1 Ore Big Data Center
Supported by big data analysis technology, based on various safety production specifications and regulations formulated by the industry, group and mine, combined with comprehensive automation, online monitoring and dynamic and historical data obtained in daily coal mine safety production, display, analyze and reason various types of information on coal mine safety production, mine the patterns and knowledge contained in historical data, diagnose and summarize the current safety status, predict future safety situations, and realize dynamic diagnosis and auxiliary decision-making for coal mine safety production.

- Safety Monitoring Big Data: Mine major disaster early warning and expert decision system multi-network integration linkage control system.
- Production Monitoring Big Data: Workflow/business process full analysis system, key equipment fault diagnosis and remote maintenance platform.
- Business Decision-making Big Data: Big data active push platform based on mobile Internet, safety production information mobile intelligent terminal system.

3.2 Smart Mine Comprehensive Management Platform

3.2.1 Mine Dynamic Supervision Capability
Make unmanned attendance, mobile inspection, video diagnosis and multimedia data collection possible, and further improve emergency response capability and scheduling management capability for safety production.

3.2.2 Mine Safety Management Capability
Realize all-round management functions for equipment, personnel, process flow, platform, applications and emergency response.

3.2.3 Decision-making Analysis Capability
Through the application of big data technology, the integrated management and control platform should have management capabilities such as decision-making analysis, accident prediction and operation guidance in the process of safety production.

3.2.4 3D Virtual Mine System
Based on information such as mine coal seams, rock strata, structures, roadways, chambers and equipment, build a "transparent coal mine" of "resource occurrence, geological structure, production system layout, production process, safety risk" in a 3D (spatio-temporal) scene, realize the smart mine information model of "engineering technology, safety production, disaster prevention and emergency response" for the entire mine, and provide basic spatial digital services and spatial analysis services for all business applications. Visually display the physical distribution of the coal mine, provide the most comprehensive integrated data integration application based on 3D models, including 3D display of the surface and underground parts of the coal mine, realize the two-way association between data of various coal mine application systems and 3D models, and conduct visual mining in a 3D environment. The 3D transparent mine platform displays the inherent spatial relationships such as working face dynamics, coal seam distribution, reserve composition, hydrogeology and geographic information, integrates mine safety monitoring information, personnel positioning information, equipment management information, mine reserve and coal seam distribution information, output monitoring information, disaster early warning information, etc., and effectively integrates multi-source geological information such as mining information, coal mine geology, hydrogeology, gas and mine pressure through 3D geological modeling technology and virtual reality technology.

3.2.5 Mine Safety Monitoring System
The safety monitoring system refers to the risk management process that, during the entire life cycle of enterprise production, pre-identifies, evaluates and classifies known hazard sources in the system, then eliminates, reduces and controls them, achieves the best matching of the man-machine-environment system, and reduces accidents to the level expected by people and acceptable by society.

3.2.6 Mine Safety Early Warning System
Integrated monitoring is carried out under a unified system operation platform to monitor and control each accessed subsystem. Data of relevant subsystems can be shared in real time, providing practical data basis guarantee for subsequent advanced system applications.
- Fault Alarm: When the equipment runs fails, the client will prompt the fault in real time, and the faults are distinguished by different colors according to the user's setting level and flashed for reminder.
- Event Record: When the user operates, the system prompts to input operation records, and all recorded information is stored in the database.
- Authorization Management: The authorization management system can realize comprehensive user and authorization management.
- Reports and Curves: Make relevant reports and curves according to the actual needs of customers, combine with the management and control information system, and view relevant reports in the system.
- WEB Browsing: You can log in to the WEB browsing website using IE to view the operating status of each subsystem in real time.

3.2.7 Alarm Information Management and Disposal System
Comprehensively integrate data from various coal mine monitoring and subsystems, centrally realize the display and processing of alarm information. Based on the accumulation of alarm information data, realize statistical analysis of various KPIs such as alarm types, levels and subsystems, providing data basis for safety decision-making. Flexibly configure the responsible subjects of classified alarm information in combination with actual business, so as to realize that the responsibility of alarm handling is assigned to individuals.

3.2.8 Mine Emergency Command System
The mine emergency command system is a remote collaborative management system with multiple locations, departments, majors, resources, systems, technologies and roles. Using geographic information technology, navigation and positioning technology, IoT technology, communication technology, typical cloud computing models, following SOA architecture, and service models such as PaaS and SaaS, finally realize emergency command with rapid response and effective rescue implementation.

3.2.9 Mineral Resources Dynamic Management System
Due to the complex mine geological environment and dynamic overpressure caused by ground economic construction, the mineable mineral resources of the mine often change. The basic mine data can be used to provide mineral resource calculation functions, input changing impact parameters and boundary conditions, and after operation and analysis, quickly and visually delineate new reserve boundaries, calculate the changed reserves of various levels and types, and support mapping output and printing.

3.2.10 Management Cockpit
The management cockpit can provide daily data of the mine. Break data isolation and realize the implementation of indicator analysis and decision-making scenarios. Through a detailed indicator system, reflect the operating status of the enterprise in real time, and visualize, intuitively and concretize the collected data. The "Management Cockpit" fully integrates the essence of human brain science, management science and information science, takes people as the core of the product, and comprehensively displays mine information in front of managers from the perspective of managers' decision-making environment, definition of enterprise management comprehensive indicators and information expression.

IV. Features and Advantages

1. Simple and Fast Construction
Set up a dedicated industrial measurement and control actuator for the controlled equipment to monitor and control the controlled equipment, with simple structure, convenient wiring and fast installation.

2. Strong Compatibility and Expandability
The system builds a gigabit fiber Ethernet ring network covering surface and underground areas, providing data bandwidth of up to 100 Mbps for multiple systems to ensure data links of each system. At the same time, the design adopts standard and open industrial Ethernet protocols, with various corresponding interfaces reserved, featuring flexibility and extensibility, and uses international standard protocols to facilitate interworking with equipment from other manufacturers.

3. Automatic System Status Detection
Analyze equipment operation, including accumulated equipment operating time, equipment fault diagnosis, equipment health analysis, equipment maintenance, alarm reminder and equipment start-stop times monitoring.

4. Industrial Ring Network Technology
The system supports industrial ring network technology, with millisecond-level ring recovery. When a single device or a certain section of the line fails, the system will automatically switch the data link to ensure the stability of data transmission. Through the network management system of the monitoring center, it can conveniently display the equipment status in the communication link and alarm the fault location, and notify the maintenance personnel in time, thus avoiding the impact on the entire system caused by the failure of a single device or a certain section of the line.
