2021年山西省大同市云冈石窟第20窟有限元模型数据

2021年对山西省大同市云冈石窟第20窟进行人工测量获取其点云数据，采用ANSYS、CAD、ABAQUS等软件建模，该三维模型的所有洞窟构造、佛像构造窟室分布、比例等均符合现实的云冈石窟第20窟。可用于石窟的重力分析和抗震性能分析，为石窟的维修加固提供技术支撑。In 2021, manual measurements were conducted on Cave 20 of the Yungang Grottoes in Datong City, Shanxi Province to obtain its point cloud data. Three-dimensional modeling was carried out using software such as ANSYS, CAD, and ABAQUS. All grotto structures, Buddha statue structures, cave chamber distributions, proportions and other relevant details of this 3D model conform to the actual Cave 20 of the Yungang Grottoes. This model can be applied to gravity analysis and seismic performance analysis of the grotto, providing technical support for the maintenance and reinforcement of the site.

搜集汇总

背景与挑战

背景概述

该数据集为2021年山西省大同市云冈石窟第20窟的有限元模型数据，通过激光扫描获取点云数据并经过专业软件建模生成，主要用于石窟结构的重力分析和抗震性能分析，为文化遗产保护提供技术支撑。
