实车转毂试验与HIL仿真测试数据

（1）实车转毂试验数据，以一款福田混动商用车为研究测试对象，在整车转毂上开展C-WTVC循环试验，循环速度曲线及试验中的变量控制和设备要求依据国标GB/T 27840-2011《重型商用车辆燃料消耗量测量方法》执行，试验过程中通过网络适配器实时采集目标车辆HCU控制器CAN总线上的发动机、电机、电池等运行数据。采集的数据可用于后续HIL仿真模型的校正与精度验证。
（2）HIL仿真测试数据，以转毂测试所用整车为目标车辆，基于Simulink建立目标车辆的整车模型，其中的子模型包括驾驶员模型、发动机模型、电机模型、动力电池模型、传动系模型和整车动力学模型。在驾驶员模型中输入C-WTVC循环速度曲线，使用xPC Target宿主机-目标机仿真平台实现整车模型实时运行，运行过程中接入目标车辆真实的HCU控制器，并用网络适配器采集HCU控制器CAN总线上的发动机、电机、电池等运行数据，与实车转毂测试数据进行对比以验证模型精度。
数据内容：发动机转速、发动机扭矩、母线电流、母线电压、电机转速、电机扭矩、电池电流、电池电压、电池SOC、档位、轮速。
采集方案：试验测试
采集地点：中国汽车工程研究院股份有限公司
数据量：4.75MB

(1) Real Vehicle Chassis Dynamometer Test Data: A Foton hybrid commercial vehicle was selected as the research and test subject, and the C-WTVC cycle test was conducted on the complete vehicle chassis dynamometer. The cycle speed profile, variable control and equipment requirements during the test were carried out in accordance with the national standard GB/T 27840-2011 "Method for Measuring Fuel Consumption of Heavy Commercial Vehicles". During the test, operating data including the engine, motor, battery and other parameters on the CAN bus of the target vehicle's HCU controller were collected in real time via a network adapter. The collected data can be used for subsequent calibration and accuracy verification of HIL simulation models.

(2) HIL Simulation Test Data: Taking the complete vehicle used in the chassis dynamometer test as the target vehicle, a complete vehicle model of the target vehicle was established based on Simulink. The sub-models of this model include the driver model, engine model, motor model, power battery model, powertrain model and vehicle dynamics model. The C-WTVC cycle speed profile was input into the driver model, and the xPC Target host-target simulation platform was used to realize the real-time operation of the complete vehicle model. During the operation, the real HCU controller of the target vehicle was connected, and the operating data such as the engine, motor, battery and other parameters on the CAN bus of the HCU controller were collected via a network adapter. These data were compared with the real vehicle chassis dynamometer test data to verify the accuracy of the model.

Data Content: Engine speed, engine torque, bus current, bus voltage, motor speed, motor torque, battery current, battery voltage, battery SOC, gear position, wheel speed.

Collection Scheme: Experimental test
Collection Location: China Automotive Engineering Research Institute Co., Ltd.
Data Volume: 4.75 MB
