ImagenWorld-annotated-set

## 📦 Dataset Access

The dataset is organized as **zipped folders** by task for both `train` and `test` splits.

### 🐍 **Download with Python**

```python
from huggingface_hub import snapshot_download
import zipfile
from pathlib import Path

# Download annotated dataset
local_path = snapshot_download(
repo_id="TIGER-Lab/ImagenWorld-annotated-set",
repo_type="dataset",
local_dir="ImagenWorld-annotated-set",
local_dir_use_symlinks=False,
)

# Unzip all tasks for each split
for split in ["train", "test"]:
split_dir = Path(local_path) / split
for zip_file in split_dir.glob("*.zip"):
target_dir = split_dir / zip_file.stem
target_dir.mkdir(exist_ok=True)
with zipfile.ZipFile(zip_file, "r") as zf:
zf.extractall(target_dir)
print(f"✅ Extracted {zip_file.name} → {target_dir}")
```

---

### 💻 **Download via Command Line**

```bash
hf download TIGER-Lab/ImagenWorld-annotated-set --repo-type dataset --local-dir ImagenWorld-annotated-set
cd ImagenWorld-annotated-set && for s in train test; do cd "$s"; for f in *.zip; do d="${f%.zip}"; mkdir -p "$d"; unzip -q "$f" -d "$d"; done; cd ..; done
```

---

## 📁 Dataset Structure

After extraction, your directory will look like this:

```
ImagenWorld-annotated-set/
│
├── train/
│ ├── TIG.zip
│ ├── TIE.zip
│ ├── SRIG.zip
│ ├── SRIE.zip
│ ├── MRIG.zip
│ └── MRIE.zip
│
├── test/
│ ├── TIG.zip
│ ├── TIE.zip
│ ├── SRIG.zip
│ ├── SRIE.zip
│ ├── MRIG.zip
│ └── MRIE.zip
```

After unzipping, each task follows this internal structure:

### 🧩 `train/` split (with human evaluation)

```
TIG/
└── TIG_A_000001/
├── input/
│ ├── metadata.json
│ ├── 1.png
│ └── ...
└── outputs/
├── sdxl/
│ ├── annotator1/
│ │ ├── evaluation.json
│ │ ├── error_mask.png # optional; only if not 'None' or 'All'
│ │ └── ...
│ ├── annotator2/
│ ├── annotator3/
│ ├── out.png # model-generated output
│ ├── som_segments.png # Set-of-Marks segmentation map (visual)
│ └── som_segments.npz # corresponding NumPy map for the above
└── gpt-image-1/
├── ...
```

### 🧠 `test/` split (without manual evaluation)

Same structure as `train/`, except **no `annotatorX/` folders** are included:

```
TIG/
└── TIG_A_000001/
├── input/
└── outputs/
├── sdxl/
│ ├── out.png
│ ├── som_segments.png
│ └── som_segments.npz
└── gpt-image-1/
```

---

## 🧾 File Descriptions

| File | Description |
|------|--------------|
| `evaluation.json` | JSON file with annotator feedback and per-object or per-segment ratings. |
| `error_mask.png` | Binary mask highlighting incorrectly generated regions (if annotator selected specific areas). |
| `som_segments.png` | Visual segmentation map generated by the **Set-of-Marks (SoM)** model. |
| `som_segments.npz` | NumPy array containing pixel-to-segment mappings corresponding to `som_segments.png`. |
| `out.png` | The raw image generated by the model for this condition set. |
| `metadata.json` | Input metadata and prompt from the original condition set. |

---

## 📊 Annotation Details

- Human annotations were collected from **three independent annotators per model output**.
- Each annotator could select:
- `None` — no error found
- `All` — the entire image contains severe issues
- or mark **specific regions** using an error mask (`error_mask.png`).
- Evaluations include **object-level**, **segment-level**, and **score-based** ratings.

---

## 🔗 Related Datasets

| Component | Description | Repository |
|------------|--------------|-------------|
| **Condition Set** | Input prompts and reference images. | [`TIGER-Lab/ImagenWorld-condition-set`](https://huggingface.co/datasets/TIGER-Lab/ImagenWorld) |
| **Model Outputs** | Generated images from all models used in evaluation. | [`TIGER-Lab/ImagenWorld-model-outputs`](https://huggingface.co/datasets/TIGER-Lab/ImagenWorld-model-outputs) |

---

## 🧠 Notes

- The **`train/` split** includes **human annotations** from multiple annotators.
- The **`test/` split** is simply the remaining portion **without** manual evaluation.
- Segmentation files (`som_segments.*`) are included for all models to support error localization and structured comparison.

---

## 📜 Citation

If you use **ImagenWorld**, please cite:

```bibtex
@misc{imagenworld2025,
title = {ImagenWorld: Stress-Testing Image Generation Models with Explainable Human Evaluation on Open-ended Real-World Tasks},
author = {Samin Mahdizadeh Sani and Max Ku and Nima Jamali and Matina Mahdizadeh Sani and Paria Khoshtab and Wei-Chieh Sun and Parnian Fazel and Zhi Rui Tam and Thomas Chong and Edisy Kin Wai Chan and Donald Wai Tong Tsang and Chiao-Wei Hsu and Ting Wai Lam and Ho Yin Sam Ng and Chiafeng Chu and Chak-Wing Mak and Keming Wu and Hiu Tung Wong and Yik Chun Ho and Chi Ruan and Zhuofeng Li and I-Sheng Fang and Shih-Ying Yeh and Ho Kei Cheng and Ping Nie and Wenhu Chen},
year = {2025},
doi = {10.5281/zenodo.17344183},
url = {https://zenodo.org/records/17344183},
projectpage = {https://tiger-ai-lab.github.io/ImagenWorld/},
blogpost = {https://blog.comfy.org/p/introducing-imagenworld},
note = {Community-driven dataset and benchmark release, Temporarily archived on Zenodo while arXiv submission is under moderation review.},
}

```

📦 数据集获取
本数据集按任务分为训练集（`train`）与测试集（`test`）两个数据划分，均以压缩文件夹形式存储。

### 🐍 Python 下载方式
python
from huggingface_hub import snapshot_download
import zipfile
from pathlib import Path

# 下载带标注的数据集
local_path = snapshot_download(
repo_id="TIGER-Lab/ImagenWorld-annotated-set",
repo_type="dataset",
local_dir="ImagenWorld-annotated-set",
local_dir_use_symlinks=False,
)

# 为每个数据划分解压所有任务数据
for split in ["train", "test"]:
split_dir = Path(local_path) / split
for zip_file in split_dir.glob("*.zip"):
target_dir = split_dir / zip_file.stem
target_dir.mkdir(exist_ok=True)
with zipfile.ZipFile(zip_file, "r") as zf:
zf.extractall(target_dir)
print(f"✅ 已解压 {zip_file.name} → {target_dir}")

---

### 💻 命令行下载方式
bash
hf download TIGER-Lab/ImagenWorld-annotated-set --repo-type dataset --local-dir ImagenWorld-annotated-set
cd ImagenWorld-annotated-set && for s in train test; do cd "$s"; for f in *.zip; do d="${f%.zip}"; mkdir -p "$d"; unzip -q "$f" -d "$d"; done; cd ..; done

---

## 📁 数据集结构
解压完成后，目录结构如下：

ImagenWorld-annotated-set/
│
├── train/
│ ├── TIG.zip
│ ├── TIE.zip
│ ├── SRIG.zip
│ ├── SRIE.zip
│ ├── MRIG.zip
│ └── MRIE.zip
│
├── test/
│ ├── TIG.zip
│ ├── TIE.zip
│ ├── SRIG.zip
│ ├── SRIE.zip
│ ├── MRIG.zip
│ └── MRIE.zip

解压单个任务压缩包后，其内部结构如下：

### 🧩 训练集（`train`，含人工评估）

TIG/
└── TIG_A_000001/
├── input/
│ ├── metadata.json
│ ├── 1.png
│ └── ...
└── outputs/
├── sdxl/
│ ├── annotator1/
│ │ ├── evaluation.json
│ │ ├── error_mask.png # 可选；仅当标注结果不为`"None"`或`"All"`时存在
│ │ └── ...
│ ├── annotator2/
│ ├── annotator3/
│ ├── out.png # 模型生成的输出图像
│ ├── som_segments.png # 标记集（Set-of-Marks，SoM）可视化分段掩码图
│ └── som_segments.npz # 上述掩码对应的像素-分段映射NumPy数组
└── gpt-image-1/
├── ...

### 🧠 测试集（`test`，无人工评估）
结构与训练集一致，但**不含`annotatorX/`系列文件夹**：

TIG/
└── TIG_A_000001/
├── input/
└── outputs/
├── sdxl/
│ ├── out.png
│ ├── som_segments.png
│ └── som_segments.npz
└── gpt-image-1/

---

## 🧾 文件说明
| 文件路径 | 描述 |
|------|--------------|
| `evaluation.json` | 包含标注员反馈与逐对象/逐分段评分的JSON文件。 |
| `error_mask.png` | 二值掩码图，用于高亮生成错误的区域（若标注员标记了特定区域）。 |
| `som_segments.png` | 由**标记集（Set-of-Marks，SoM）**模型生成的可视化分段掩码图。 |
| `som_segments.npz` | 与`som_segments.png`对应的像素-分段映射NumPy数组文件。 |
| `out.png` | 模型基于当前条件集生成的原始图像。 |
| `metadata.json` | 原始条件集的输入元数据与提示词。 |

---

## 📊 标注细节
- 每个模型输出均由**三名独立标注员**完成人工标注。
- 每位标注员可选择以下标注结果：
- `"None"` — 未发现错误
- `"All"` — 整张图像存在严重问题
- 或使用错误掩码图（`error_mask.png`）标记**特定错误区域**。
- 评估内容包含**对象级、分段级与评分级**三类标注。

---

## 🔗 关联数据集
| 组件 | 描述 | 仓库地址 |
|------------|--------------|-------------|
| **条件集（Condition Set）** | 输入提示词与参考图像。 | [`TIGER-Lab/ImagenWorld-condition-set`](https://huggingface.co/datasets/TIGER-Lab/ImagenWorld) |
| **模型输出集（Model Outputs）** | 评估所用全部模型生成的图像。 | [`TIGER-Lab/ImagenWorld-model-outputs`](https://huggingface.co/datasets/TIGER-Lab/ImagenWorld-model-outputs) |

---

## 🧠 注意事项
- 训练集（`train`）包含多名标注员的**人工标注数据**。
- 测试集（`test`）为剩余未标注的数据集子集。
- 所有模型均附带分段文件（`som_segments.*`），以支持错误定位与结构化对比分析。

---

## 📜 引用格式
若您使用**ImagenWorld**数据集，请引用以下文献：
bibtex
@misc{imagenworld2025,
title = {ImagenWorld: Stress-Testing Image Generation Models with Explainable Human Evaluation on Open-ended Real-World Tasks},
author = {Samin Mahdizadeh Sani and Max Ku and Nima Jamali and Matina Mahdizadeh Sani and Paria Khoshtab and Wei-Chieh Sun and Parnian Fazel and Zhi Rui Tam and Thomas Chong and Edisy Kin Wai Chan and Donald Wai Tong Tsang and Chiao-Wei Hsu and Ting Wai Lam and Ho Yin Sam Ng and Chiafeng Chu and Chak-Wing Mak and Keming Wu and Hiu Tung Wong and Yik Chun Ho and Chi Ruan and Zhuofeng Li and I-Sheng Fang and Shih-Ying Yeh and Ho Kei Cheng and Ping Nie and Wenhu Chen},
year = {2025},
doi = {10.5281/zenodo.17344183},
url = {https://zenodo.org/records/17344183},
projectpage = {https://tiger-ai-lab.github.io/ImagenWorld/},
blogpost = {https://blog.comfy.org/p/introducing-imagenworld},
note = {Community-driven dataset and benchmark release, Temporarily archived on Zenodo while arXiv submission is under moderation review.},
}
