桩板式结构成套标准图服务

桩板式道路结构作为一种新型公路结构，是一种打破传统桥梁和道路结构分类界限，优势融合的创新体系。桩板式道路结构：采用预制管桩+预制桥面板的小型桥梁结构形式，代替传统的填土路基，具备工业化建造程度高、施工快速和造价可控的优势。经过多年的工程实践和不断创新，公路桩板式结构已发展出6m、12m、13m和16m等多种跨径，已形成了新建及改扩建桩板式道路系列标准图，可供设计和施工使用。

As a novel highway structure, the pile-slab road structure is an innovative system that breaks the classification boundaries between traditional bridge and road structures and integrates their respective advantages. The pile-slab road structure, which adopts the small-scale bridge structure form combining precast tubular piles and precast bridge decks, replaces traditional filled subgrades, and boasts advantages such as high degree of industrialized construction, rapid construction and controllable project costs. After years of engineering practice and continuous innovation, the highway pile-slab structure has developed various spans including 6m, 12m, 13m and 16m, and a series of standard drawings for new construction, expansion and renovation of pile-slab roads has been formulated, which is available for design and construction purposes.

搜集汇总

背景与挑战

背景概述

该数据集由安徽省交通规划设计研究总院股份有限公司提供，包含桩板式道路结构的成套标准图，涵盖6m至16m多种跨径，适用于公路设计和施工，具有工业化建造和施工效率高的优势。
