FASTENING ASSEMBLY
收藏资源简介：
Provided is a fastening assembly (1)， comprising a sliding column (11) and a sliding groove (12). The sliding column (11) comprises a fixed part (111) arranged on a surface， opposite a second mounting member (3)， of a first mounting member (2)， and an extension part (112) connected to the fixed part (111). The sliding groove (12) is formed on a surface， opposite the first mounting member (2)， of the second mounting member (3); the sliding groove (12) is provided with an avoidance space (121) used for inserting the extension part (112) into the sliding groove (12)， and a fastening space (122) used for clamping the extension part (112) in the sliding groove; and a bottom face of the fastening space (122) is provided with a locking hole (100)， and a limiting space (123) that is used for restricting the extension part (112) from sliding from the avoidance space (121) to the fastening space (122) in a second direction. A user does not require other additional mounting tools when assembling the first mounting member (2) and the second mounting member (3)， and operation is easy and convenient; and an assembled finished product is good quality and has a good connection stability， looseness is avoided， and the service life of the finished product is prolonged.
本紧固件组件(1)包括滑柱(11)与滑槽(12)。滑柱(11)包含固定部(111)与连接于该固定部(111)的延伸部(112)，其中固定部(111)设置于第一安装件(2)朝向第二安装件(3)的表面。滑槽(12)开设于第二安装件(3)朝向第一安装件(2)的表面；滑槽(12)设有供延伸部(112)插入滑槽(12)的避让空间(121)，以及用于将延伸部(112)卡接于滑槽内的紧固空间(122)。且紧固空间(122)的底面开设有锁孔(100)，以及用于限制延伸部(112)沿第二方向从避让空间(121)滑入紧固空间(122)的限位空间(123)。 在组装第一安装件(2)与第二安装件(3)时，无需借助其他额外安装工具，操作简便快捷；组装后的成品品质优良，连接稳定性佳，可避免出现松动现象，延长了成品的使用寿命。
