SOUNDPROOF PANEL AND SOUNDPROOF STRUCTURE

A soundproof panel comprising a nonwoven structural member and a board member is prepared. The nonwoven structural member comprises a thermal adhesive fiber under moisture which is melt-bonded to a fiber of the structural member to fix the fibers. The soundproof panel may be a soundproof panel 1 comprising a nonwoven structural member 2 and a honeycomb member 3 stacked thereto. Moreover， the soundproof panel may be a soundproof panel comprising a board-like nonwoven structural member and first and second surface members stacked to first and second sides of the board-like nonwoven structural member， respectively. Further， the soundproof panel may be a soundproof panel having first and second surface members stacked through a square-pole rail member comprising a nonwoven structural member. The soundproof panel of the present invention has toughness for the lightweight design and has excellent sound absorption and sound insulation properties.

本发明提供一种隔音板（soundproof panel），其包含非织造结构件（nonwoven structural member）与板状构件。该非织造结构件包含热粘合纤维（thermal adhesive fiber），此类纤维在潮湿环境下可通过熔融粘合作用与结构件自身的纤维结合，从而实现纤维的固定。该隔音板可为包含非织造结构件2与堆叠于其上的蜂窝构件3的隔音板1。此外，该隔音板还可包含板状非织造结构件（board-like nonwoven structural member），以及分别堆叠于该板状非织造结构件第一侧与第二侧的第一表面构件和第二表面构件。进一步地，该隔音板也可为通过包含非织造结构件的方柱形轨状构件（square-pole rail member）实现第一表面构件与第二表面构件堆叠的结构。本发明的隔音板兼具轻量化设计所需的韧性与优异的吸声及隔声性能。

搜集汇总

背景与挑战

背景概述

该数据集描述了一种由无纺布结构件和板件组成的隔音板及其结构。这种隔音板设计轻巧且坚固，并具备出色的吸音和隔音性能。其具体构造可能包括蜂窝构件或通过方杆导轨连接的表层构件等多种形式。
