Ming-Freeform-Audio-Edit-Benchmark

# README

## Introduction
This repository hosts Ming-Freeform-Audio-Edit, the benchmark test set for evaluating the downstream editing tasks of the Ming-UniAudio model.

This test set covers 7 distinct editing tasks, categorized as follows:

+ Semantic Editing (3 tasks):

+ Free-form Deletion
+ Free-form Insertion
+ Free-form Substitution
+ Acoustic Editing (5 tasks):
+ Time-stretching
+ Pitch Shifting
+ Dialect Conversion
+ Emotion Conversion
+ Volume Conversion

The audio samples are sourced from well-known open-source datasets, including seed-tts eval, LibriTTS, and Gigaspeech.

## Dataset statistics
### Semantic Editing
#### full version
| Task Types\ # samples \ Language | Zh deletion | Zh insertion | Zh substitution | En deletion | En insertion | En substitution |
| -------------------------------- | ----------: | -----------: | --------------: | ----------: | -----------: | --------------: |
| Index-based | 186 | 180 | 36 | 138 | 100 | 67 |
| Content-based | 95 | 110 | 289 | 62 | 99 | 189 |
| Total | 281 | 290 | 325 | 200 | 199 | 256 |

#### basic version
| Task Types\ # samples \ Language | Zh deletion | Zh insertion | Zh substitution | En deletion | En insertion | En substitution |
| -------------------------------- | ----------: | -----------: | --------------: | ----------: | -----------: | --------------: |
| Index-based | 92 | 65 | 29 | 47 | 79 | 29 |
| Content-based | 78 | 105 | 130 | 133 | 81 | 150 |
| Total | 170 | 170 | 159 | 180 | 160 | 179 |

*Index-based* instruction: specifies an operation on content at positions *i* to *j*. (e.g. delete the characters or words from index 3 to 12)

*Content-based*: targets specific characters or words for editing. (e.g. insert 'hello' before 'world')
### Acoustic Editing
| Task Types\ # samples \ Language | Zh | En |
| -------------------------------- | ---: | ---: |
| Time-stretching | 50 | 50 |
| Pitch Shifting | 50 | 50 |
| Dialect Conversion | 250 | --- |
| Emotion Conversion | 84 | 72 |
| Volume Conversion | 50 | 50 |
## Evaluation Metrics
### Environment Preparation
```bash
git clone https://github.com/inclusionAI/Ming-Freeform-Audio-Edit.git
cd Ming-Freeform-Audio-Edit
pip install -r requirements.txt
```
**Note**: Please download the audio and meta files from [HuggingFace](https://huggingface.co/datasets/inclusionAI/Ming-Freeform-Audio-Edit-Benchmark/tree/main) or [ModelScope](https://modelscope.cn/datasets/inclusionAI/Ming-Freeform-Audio-Edit-Benchmark/files) and put the `wavs` and `meta` directories under `Ming-Freeform-Audio-Edit`
### Semantic Editing
For the deletion, insertion, and substitution tasks, we evaluate the performance using four key metrics:
+ Word Error Rate (WER) of the Edited Region (wer)
+ Word Error Rate (WER) of the Non-edited Region (wer.noedit)
+ Edit Operation Accuracy (acc)
+ Speaker Similarity (sim)

1. If you have organized the directories contain edited waveforms like below:
```
eval_path
|
├── del
│ └── edit_del_basic
│ └── tts/ # This is the actual directory contains the edited wavs
├── ins
│ └── edit_ins_basic
│ └── tts/ # This is the actual directory contains the edited wavs
├── sub
└── edit_sub_basic
└── tts/ # This is the actual directory contains the edited wavs
```
Then you can run the following command to get those metrics:
```bash
cd Ming-Freeform-Audio-Edit/eval_scripts
bash run_eval_semantic.sh eval_path \
whisper_path \
paraformer_path \
wavlm_path \
eval_mode \
lang
```
Here is a brief description of the parameters for the script above:
+ `eval_path`: The top-level directory containing subdirectories for each editing task
+ `whisper_path`:Path to the Whisper model, which is used to calculate WER for English audio. You can download it from [here](https://huggingface.co/openai/whisper-large-v3).
+ `paraformer_path`:Path to the Paraformer model, which is used to calculate WER for Chinese audio. You can download it from [here](https://huggingface.co/funasr/paraformer-zh).
+ `wavlm_path`: Path to the WavLM model, which is used to calculate speaker similarity. You can download it from [here](https://drive.google.com/file/d/1-aE1NfzpRCLxA4GUxX9ITI3F9LlbtEGP/view).
+ `eval_mode`: Used to specify which version of the evaluation set to use. Choose between `basic` and `open`
+ `lang`: supported language, choose between `zh` and `en`

2. If your directory for the edited audio is not organized in the format described above, you can run the following commands.
```bash
cd eval_scripts
# get wer, wer.noedit
bash cal_wer_edit.sh meta_file \
wav_dir \
lang \
num_jobs \
res_dir \
task_type \
eval_mode \
whisper_path \
paraformer_path \
edit_cat # use `semantic` here
# get sim
bash cal_sim_edit.sh meta_file \
wav_dir \
wavlm_path \
num_jobs \
res_dir \
lang
```
Here is a brief description of the parameters for the script above:
+ `meta_file`: The absolute path to the meta file for the corresponding task (e.g., `meta_en_deletion_basic.csv` or `meta_en_deletion.csv`).
+ `wav_dir`: The directory containing the edited audio files (the WAV files should be located directly in this directory).
+ `lang`: `zh` or `en`
+ `num_jobs`: number of process.
+ `res_dir`: The directory to save the metric results.
+ `task_type`: `del`, `ins` or `sub`
+ `eval_mode`: The same as the above.
+ `whisper_path`: The same as the above
+ `paraformer_path`: The same as the above
+ `edit_cat`: `semantic` or `acoustic`

### Acoustic Editing
For the acoustic editing tasks, we use WER and SPK-SIM as the primary evaluation metrics.

1. If the directory for the edited audio is structured, you can run the following command.
```bash
cd Ming-Freeform-Audio-Edit/eval_scripts
bash run_eval_acoustic.sh eval_path \
whisper_path \
paraformer_path \
wavlm_path \
eval_mode \
lang
```
2. Otherwise, you can run commands similar to the one for the semantic tasks, with the `edit_cat` parameter set to `acoustic`.

Additionally, for the dialect and emotion conversion tasks, we assess the conversion accuracy by leveraging a large language model (LLM) through API calls, refer to `eval_scripts/run_eval_acoustic.sh` for more details.

# 说明文档（README）

## 简介
本仓库托管**Ming-Freeform-Audio-Edit**数据集，该数据集是用于评估Ming-UniAudio模型下游音频编辑任务的基准测试集。

该测试集涵盖7类不同的音频编辑任务，分类如下：
+ 语义编辑（3项子任务）：
+ 自由式删除（Free-form Deletion）
+ 自由式插入（Free-form Insertion）
+ 自由式替换（Free-form Substitution）
+ 声学编辑（5项子任务）：
+ 时间拉伸（Time-stretching）
+ 音调偏移（Pitch Shifting）
+ 方言转换（Dialect Conversion）
+ 情感转换（Emotion Conversion）
+ 音量转换（Volume Conversion）

该数据集的音频样本源自多个知名开源数据集，包括seed-tts eval、LibriTTS以及Gigaspeech。

## 数据集统计
### 语义编辑
#### 完整版
| 任务类型#样本数 语言 | 中文删除 | 中文插入 | 中文替换 | 英文删除 | 英文插入 | 英文替换 |
| -------------------------------- | ----------: | -----------: | --------------: | ----------: | -----------: | --------------: |
| 基于索引（Index-based） | 186 | 180 | 36 | 138 | 100 | 67 |
| 基于内容（Content-based） | 95 | 110 | 289 | 62 | 99 | 189 |
| 总计（Total） | 281 | 290 | 325 | 200 | 199 | 256 |

#### 基础版
| 任务类型#样本数 语言 | 中文删除 | 中文插入 | 中文替换 | 英文删除 | 英文插入 | 英文替换 |
| -------------------------------- | ----------: | -----------: | --------------: | ----------: | -----------: | --------------: |
| 基于索引（Index-based） | 92 | 65 | 29 | 47 | 79 | 29 |
| 基于内容（Content-based） | 78 | 105 | 130 | 133 | 81 | 150 |
| 总计（Total） | 170 | 170 | 159 | 180 | 160 | 179 |

**基于索引**指令：指定对位置*i*至*j*处的内容执行编辑操作（例如删除索引3至12处的字符或单词）。

**基于内容**：针对特定字符或单词执行编辑操作（例如在"world"前插入"hello"）。

### 声学编辑
| 任务类型#样本数 语言 | 中文 | 英文 |
| -------------------------------- | ---: | ---: |
| 时间拉伸（Time-stretching） | 50 | 50 |
| 音调偏移（Pitch Shifting） | 50 | 50 |
| 方言转换（Dialect Conversion） | 250 | --- |
| 情感转换（Emotion Conversion） | 84 | 72 |
| 音量转换（Volume Conversion） | 50 | 50 |

## 评估指标
### 环境配置
bash
git clone https://github.com/inclusionAI/Ming-Freeform-Audio-Edit.git
cd Ming-Freeform-Audio-Edit
pip install -r requirements.txt

**注意**：请从[HuggingFace](https://huggingface.co/datasets/inclusionAI/Ming-Freeform-Audio-Edit-Benchmark/tree/main)或[ModelScope](https://modelscope.cn/datasets/inclusionAI/Ming-Freeform-Audio-Edit-Benchmark/files)下载音频与元数据文件，并将`wavs`和`meta`目录放置于`Ming-Freeform-Audio-Edit`目录下。

### 语义编辑
针对删除、插入与替换任务，我们采用四项核心指标评估模型性能：
+ 编辑区域词错误率（Word Error Rate，WER，简称wer）
+ 非编辑区域词错误率（Word Error Rate，WER，简称wer.noedit）
+ 编辑操作准确率（Edit Operation Accuracy，简称acc）
+ 说话人相似度（Speaker Similarity，简称sim）

1. 若您的编辑后音频波形目录结构如下所示：

eval_path
|
├── del
│ └── edit_del_basic
│ └── tts/ # 此处为存放编辑后音频文件的实际目录
├── ins
│ └── edit_ins_basic
│ └── tts/ # 此处为存放编辑后音频文件的实际目录
├── sub
└── edit_sub_basic
└── tts/ # 此处为存放编辑后音频文件的实际目录

则可运行以下命令获取上述指标：
bash
cd Ming-Freeform-Audio-Edit/eval_scripts
bash run_eval_semantic.sh eval_path
whisper_path
paraformer_path
wavlm_path
eval_mode
lang

下文为该脚本参数的简要说明：
+ `eval_path`：包含各编辑任务子目录的顶级目录
+ `whisper_path`：Whisper模型的路径，用于计算英文音频的词错误率，可从[此处](https://huggingface.co/openai/whisper-large-v3)下载
+ `paraformer_path`：Paraformer模型的路径，用于计算中文音频的词错误率，可从[此处](https://huggingface.co/funasr/paraformer-zh)下载
+ `wavlm_path`：WavLM模型的路径，用于计算说话人相似度，可从[此处](https://drive.google.com/file/d/1-aE1NfzpRCLxA4GUxX9ITI3F9LlbtEGP/view)下载
+ `eval_mode`：用于指定使用哪个版本的测试集，可选值为`basic`（基础版）与`open`（开放版）
+ `lang`：支持的语言，可选值为`zh`（中文）与`en`（英文）

2. 若您的编辑后音频目录未按上述格式组织，则可运行以下命令：
bash
cd eval_scripts
# 计算wer、wer.noedit
bash cal_wer_edit.sh meta_file
wav_dir
lang
num_jobs
res_dir
task_type
eval_mode
whisper_path
paraformer_path
edit_cat # 此处设置为`semantic`
# 计算sim
bash cal_sim_edit.sh meta_file
wav_dir
wavlm_path
num_jobs
res_dir
lang

下文为上述命令参数的简要说明：
+ `meta_file`：对应任务的元数据文件的绝对路径（例如`meta_en_deletion_basic.csv`或`meta_en_deletion.csv`）
+ `wav_dir`：存放编辑后音频文件的目录（WAV文件需直接置于该目录下）
+ `lang`：可选`zh`（中文）或`en`（英文）
+ `num_jobs`：并行进程数
+ `res_dir`：用于保存指标结果的目录
+ `task_type`：任务类型，可选`del`（删除）、`ins`（插入）或`sub`（替换）
+ `eval_mode`：与前文定义一致
+ `whisper_path`：与前文定义一致
+ `paraformer_path`：与前文定义一致
+ `edit_cat`：编辑类别，可选`semantic`（语义编辑）或`acoustic`（声学编辑）

### 声学编辑
针对声学编辑任务，我们采用词错误率（WER）与说话人相似度（SPK-SIM）作为核心评估指标。

1. 若编辑后音频目录结构规范，则可运行以下命令：
bash
cd Ming-Freeform-Audio-Edit/eval_scripts
bash run_eval_acoustic.sh eval_path
whisper_path
paraformer_path
wavlm_path
eval_mode
lang

2. 反之，您可运行与语义编辑任务类似的命令，仅需将`edit_cat`参数设置为`acoustic`（声学编辑）。

此外，针对方言转换与情感转换任务，我们通过调用大语言模型（LLM）的API来评估转换准确率，详细步骤可参考`eval_scripts/run_eval_acoustic.sh`文件。
