紧固件数字库-DIN6923螺母编码管理数据

本数据有助于紧固件DIN6923螺母产品属性管理及产品唯一简化编码生成和管理，实现产品的唯一性匹配。六角法兰螺母产品属性繁多有如：产品类目、产品标准名称、产品标准代号、产品规格（由直径、牙距、牙型组成）、材质、强度、材料、表面处理等11个属性构成，本数据通过将产品11个属性名称和属性值进行统一规范的管理，产品描述的所有属性值多的长达50个文字以上，很难在后续的ERP、WMS、MES等系统中调用和描述，并且无法进行产品唯一性的匹配和管理，为此将产品的11个属性值通过类似于Base64 的自定义编码（仅包含字母和数字一共33个）的方式转换成12~19位长的产品唯一编码实现产品的唯一性匹配和检索，并且通过产品的唯一性编码生成一个对于的产品二维码，快速的进行扫码识别进行后续系统平台的调用。1、数据采集：
通过国家发行的紧固件标准手册、螺纹公差、机械性能、材质手册等，获得紧固件DIN6923螺母产品的属性数据和参数，从本单位开发运营的“工业零部件数字库-【紧固件】标准底层系统”上采集紧固件产品的属性数据，包括：标准名称、标准代号、产品规格（细化为直径、牙距、牙型等四项）、材质、强度、材料、材料化学成分、材料机械性能、表面处理等并生成属性对应的ID代号。
2、算法加工方法：
第一步：从工业零部件数字库-紧固件中获取产品数据，包括品类、标准【标准名称和标准代号】、规格（由直径、牙距、牙型组成）以及材质、强度、材料、表色等数据及属性对应的ID代号。
第二步：将获取的品类、标准、规格3个属性的的ID号，使用33位自定义编码（仅含字母和数字：H1VGSCNXQTF6L7MR2UB04ZP89JE5Y3DKWA）转换成特定的短编码。
第三步：将获取的材质、强度、材料、表色属性值字符串通过哈希算法得到哈希值，再将哈希值使用33位自定义编码转换成特定的短编码。
第四部：将步骤二、三转换后获得的，品类、标准、规格及其他属性的自定义短码通过横杠连接在一起形成产品的唯一编码。

This dataset facilitates attribute management, generation and management of simplified unique codes, as well as unique product matching for DIN 6923 hexagon flange nut fasteners. The DIN 6923 hexagon flange nuts have a total of 11 attributes, including product category, product standard name, product standard code, product specification (composed of diameter, thread pitch, and thread form), material quality, strength grade, material, and surface treatment.

This dataset uniformly and standardly manages the 11 attribute names and their corresponding values. However, some product description attribute values can exceed 50 characters in length, making it difficult to call and describe in subsequent systems such as ERP, WMS, and MES, and also preventing unique product matching and management. To solve this problem, the 11 attribute values are converted into 12 to 19-digit unique product codes via a custom encoding scheme similar to Base64, which uses 33 alphanumeric characters. This enables unique product matching and retrieval. Additionally, a corresponding product QR code is generated based on the unique product code, allowing fast scanning and recognition for invocation by subsequent system platforms.

### 1. Data Collection
Attribute data and parameters of DIN 6923 hexagon flange nut fasteners are obtained from nationally issued fastener standard manuals, thread tolerance specifications, mechanical property standards, and material quality manuals. Attribute data of fastener products is also collected from the "Industrial Parts Digital Library - [Fasteners] Standard Underlying System" developed and operated by our unit, including standard name, standard code, product specification (refined into four items: diameter, thread pitch, and thread form), material quality, strength grade, material, material chemical composition, material mechanical properties, and surface treatment, with corresponding ID codes generated for each attribute.

### 2. Algorithm Processing Method
Step 1: Obtain product data from the Industrial Parts Digital Library - Fasteners, including category, standard (standard name and standard code), specification (composed of diameter, thread pitch, and thread form), material quality, strength grade, material, surface finish, and their corresponding attribute ID codes.
Step 2: Convert the ID codes of the three attributes (category, standard, and specification) into specific short codes using the 33-character custom alphanumeric encoding set: H1VGSCNXQTF6L7MR2UB04ZP89JE5Y3DKWA.
Step 3: Calculate the hash value of the attribute value strings for material quality, strength grade, material, and surface finish using a hash algorithm, then convert the hash value into a specific short code using the same 33-character custom encoding.
Step 4: Connect the custom short codes of the category, standard, specification, and other attributes obtained from Steps 2 and 3 with hyphens to form the unique product code.

搜集汇总

数据集介绍

特点

该数据集为紧固件DIN6923螺母的编码管理数据，包含11个产品属性，通过自定义编码生成唯一产品编码，用于产品唯一性匹配和管理。数据集规模1035条，每周更新。
