人字齿轮传动精度测试数据

人字齿轮传动精度测试数据主要面向齿轮传动精度测试研究，基于大连理工大学的海德汉圆光栅角度编码器MPR5080产生，在人字齿轮传动系统的输入端和输出端布置圆光栅角度编码器，测试输入和输出的转角，进而获得人字齿轮传动精度数据，主要记录人字齿轮传动误差，数据量为50KB。The herringbone gear transmission accuracy test dataset is primarily intended for research on gear transmission accuracy testing. It is developed based on the Heidenhain MPR5080 circular grating angular encoder from Dalian University of Technology. Circular grating angular encoders are deployed at both the input and output ends of the herringbone gear transmission system to measure the input and output rotational angles, thereby acquiring the herringbone gear transmission accuracy data. The dataset mainly records the transmission errors of herringbone gear transmissions, with a total size of 50 KB.

搜集汇总

背景与挑战

背景概述

该数据集面向人字齿轮传动精度测试研究，基于海德汉圆光栅角度编码器MPR5080采集输入和输出转角数据，记录了人字齿轮传动误差。数据量较小，为50KB，主要用于传动精度分析。
