数控机床热特性有限元分析数据集

数控机床热特性有限元分析数据集主要面向数控机床的热特性有限元分析研究，用于误差形成机理的相关研究，利用Dell T7920塔式工作站进行运算，采用Hypermesh进行有限元前处理，ABAQUS进行有限元仿真，仿真对象为重庆机床YS7232磨齿机，主要产生了机床的温度场数据与热误差场数据，数据量2.8GB。

This dataset for finite element analysis of thermal characteristics of CNC machine tools is primarily intended for research on finite element analysis of CNC machine tools' thermal characteristics and related studies on the error formation mechanism. The dataset was computed using a Dell T7920 tower workstation, where finite element preprocessing was carried out via Hypermesh and finite element simulation was implemented with ABAQUS. The simulation target is the YS7232 gear grinding machine produced by Chongqing Machine Tool. The dataset mainly includes temperature field data and thermal error field data of the machine tool, with a total size of 2.8 GB.

搜集汇总

背景与挑战

背景概述

该数据集专注于数控机床热特性的有限元分析，旨在研究误差形成机理，通过仿真重庆机床YS7232磨齿机，生成了温度场和热误差场数据，总数据量为2.81GB。数据集采用Hypermesh和ABAQUS软件进行前处理和仿真，来源于国家重点研发计划项目，适用于机床技术和机械工程领域的研究。
