3GSps 12bit ADC数据手册

AAD12S3000 是采用CMOS 40nm 工艺制造的高速模数转换芯片。该芯片内含四个最高可工作在750Msps 的子ADC，可以将宽带输入模拟信号转换为数字信号，并通过符合JESD204B 的高速串行接口输出。输入信号共模电压约为1.5V，差模满量程峰峰值约为1200mV ， 输出串行接口数据率为2.5*FsGbps/lane（Fs 为采样率），全速率下支持8 路串行数据输出。AAD12S3000 is a high-speed analog-to-digital conversion (ADC) chip fabricated using a 40nm CMOS process. This chip incorporates four sub-ADCs with a maximum operating rate of 750 Msps, which can convert wideband input analog signals into digital signals and output the converted data via high-speed serial interfaces compliant with the JESD204B standard. The common-mode voltage of the input signal is approximately 1.5 V, and the differential-mode full-scale peak-to-peak voltage is about 1200 mV. The data rate of the output serial interface is 2.5×Fs Gbps per lane (where Fs represents the sampling rate), and it supports 8-channel serial data output at full rate.
