HRSBallast: A collection of high-resolution, scanned railway ballast samples

HRSBallast is a collection of high-resolution, scanned railway ballast samples obtained from both a field installation and from a local quarry. The samples represent a variety of geometric properties, particularly the extend of rounding owing to in-service conditions experienced and as a function of the track performance. HRSBallast serves as a reference dataset for granular media (GM) simulations utilizing DEM (discrete element method), degradation or wear modelling, digital assets for the creation of synthetic datasets for deep learning applications, embedded railway instrumentation and video games requiring high resolution geometry.

The 108 digitized samples are provided in an STL (stereolithography) file format. Both the original resolution files are provided (HighRes.zip) alongside a decimated collection consisting of 1% of the number of points of the high resolution collection (LowRes.zip).
45 of the 108 scans samples represent the ballast samples collected from the field installation (15 samples each from three location). Each of the locations provided either angular, semi-angular of rounded ballast samples. These files are denoted as FA0-FA9 (field samples, angular), FB0-FB9 (field sample, semi-angular) and FC0-FC9 (field sample, rounded).
The remaining 63 samples were collected from the fresh ballast samples. Three experiments consisting of 10 samples each were carried out that produced these digital models:
+ fresh ballast (M00-M09) subjected to 100,000 load cycles in the small-scale box test, scanned again after the test (M10-M19),
+ fresh ballast placed in a concrete mixer for 15 minutes (M0A-M0J) and subjected to 100,000 load cycles in the small-scale box test, scanned again after the test (M1A-M1J), and
+ fresh ballast placed in a concrete mixer for 30 minutes (M0K-M0T) and subjected to 100,000 load cycles in the small-scale box test, scanned again after the test (M1K-M1T).
Note: an additional 3 files were created from ballast samples that fractured during testing.

The mass, volume, surface area and vertex count of each is provided in the spreadsheet / CSV file together with the samples identification number (Ballast_properties.xlsx). A high-resolution photograph of each sample is provided (SamplePhotos.zip).

List of files
+ Ballast_Properties.csv - 6 kb
+ Ballast_Properties.xlsx - 22 kb
+ HighRes.zip - 6.8 Gb
+ LowRes.zip - 66 Mb
+ SamplePhotos.zip - 320 Mb
+ scanning_process.MOV - 19 Mb
