# Timewarp datasets

This dataset contains molecular dynamics simulation data that was used to train the neural networks in the NeurIPS 2023 paper [Timewarp: Transferable Acceleration of Molecular Dynamics by Learning Time-Coarsened Dynamics](https://arxiv.org/abs/2302.01170) by Leon Klein, Andrew Y. K. Foong, Tor Erlend Fjelde, Bruno Mlodozeniec, Marc Brockschmidt, Sebastian Nowozin, Frank Noé, and Ryota Tomioka.
Please see the [accompanying GitHub repository](https://github.com/microsoft/timewarp).

This dataset consists of many molecular dynamics trajectories of small peptides (2-4 amino acids) simulated with an implicit water force field.
For each protein two files are available:

* `protein-state0.pdb`: contains the topology and initial 3D XYZ coordinates.
* `protein-arrays.npz`: contains trajectory information.

The datasets are are split into the following directories:

# 2AA-1-big "Two Amino Acid" data set

This folder contains a data set of all-atom molecular dynamics trajectories for 380
of the 400 dipeptides, i.e. small proteins composed of two amino acids.
This dataset was orginally created missing 20 of the 400 possible dipeptides.
The `2AA-1-complete` dataset completes this by including all 400.
Each peptide is simulated using classical molecular dynamics and the
water is simulated using an implicit water model.
The trajectories are only saved every 10000 MD steps. There is no intermediate
spacing as for the other datasets for the Timewarp project.

# 2AA-1-complete "Two Amino Acid" data set

This folder contains a data set of all-atom molecular dynamics trajectories for all 400
dipeptides, i.e. small proteins composed of two amino acids.
This includes also the peptides missing in the other 2AA datasets.
Each peptide is simulated using classical molecular dynamics and the
water is simulated using an implicit water model.

# 4AA-huge "Four Amino Acid" data set, tetrapeptides

This folder contains a data set of all-atom molecular dynamics trajectories for
tetrapeptides, i.e. small proteins composed of four amino acids.
The data set contains mostly validation and test trajectories as it was mostly
used to validation and test purposes.
The training trajectories used are usually shorter.
Each peptide is simulated for 1 micro second using classical molecular dynamics and the
water is simulated using an implicit water model.

# 4AA-large "Four Amino Acid" data set, tetrapeptides

This folder contains a data set of all-atom molecular dynamics trajectories for
2333 tetrapeptides, i.e. small proteins composed of four amino acids.
The data set is split into 1500 tetra-peptides in the train set, 400 in validation, and 433 in test.
Each peptide in the train set is simulated for 50ns using classical molecular dynamics and the
water is simulated using an implicit water model. Each other peptide is simulated for 500ns.

# AD-3 Alanine dipeptide data set
This folder contains a minimal data set of two long MD trajectories for alanine
dipeptide, the simplest dipeptide (22 atoms).

## Model training and checkpoints
Model checkpoints and config files are also included, and source code for training the model can be found [here](https://github.com/microsoft/timewarp).

## Responsible AI FAQ
- What is Timewarp?
- Timewarp is a neural network that predicts the future 3D positions of a small peptide (2- 4 amino acids) based on its current state. It is a research project that investigates using deep learning to accelerate molecular dynamics simulations.
- What can Timewarp do?
- Timewarp can be used to sample from the equilibrium distribution of small peptides.
- What is/are Timewarp’s intended use(s)?
- Timewarp is intended for machine learning and molecular dynamics research purposes only.
- How was Timewarp evaluated? What metrics are used to measure performance?
- Timewarp was evaluated by comparing the speed of molecular dynamics sampling with standard molecular dynamics systems that rely on numerical integration. Timewarp is sometimes faster than these standard systems.
- What are the limitations of Timewarp? How can users minimize the impact of Timewarp’s limitations when using the system?
- As a research project, Timewarp has many limitations. The main ones are that it only works for very small peptides (2-4 amino acids), and that it does not lead to a wall-clock speed up for many peptides.
- What operational factors and settings allow for effective and responsible use of Timewarp?
- Timewarp should be used purely for research purposes only.
