大负载超声振动磨削系统的设计

设计了一种大负载超声振动磨削系统，超声系统由换能器、圆柱圆锥形变幅杆和轮辐式砂轮组成。首先将轮辐式砂轮等效成轮毂为圆柱杆、辐板与轮缘为中厚板的复合模型，利用各接触面边界连续的条件推导系统的频率方程，完成了超声磨削系统的设计，制作了实验装置并分析验证了其声学振动特性。实验结果表明：利用轮辐式砂轮复合模型求解系统频率方程，在解决大负载超声振动磨削系统设计难题上的有效性。该超声系统结构简单，声学振动特性稳定，可输出均匀的位移振幅，有望在大负载的超声磨削领域获得应用。A high-load ultrasonic vibration grinding system was designed, which comprises a transducer, a cylindrical-cone ultrasonic horn, and a spoke-type grinding wheel. First, the spoke-type grinding wheel was equivalent to a composite model where the wheel hub is a cylindrical rod, while the spokes and rim are medium-thick plates. The frequency equation of the system was derived based on the boundary continuity conditions of each contact surface, and the design of the ultrasonic grinding system was completed. An experimental setup was fabricated, and its acoustic and vibration characteristics were analyzed and verified. Experimental results demonstrate that solving the system frequency equation via the spoke-type grinding wheel composite model is effective in addressing the design challenges of high-load ultrasonic vibration grinding systems. This ultrasonic system has a simple structure, stable acoustic and vibration characteristics, and can output uniform displacement amplitude, showing promising application prospects in the field of high-load ultrasonic grinding.

搜集汇总

背景与挑战

背景概述

该数据集设计了一种大负载超声振动磨削系统，由换能器、变幅杆和轮辐式砂轮组成，通过建立复合模型推导频率方程并完成系统设计。实验验证了该系统的有效性和稳定的声学振动特性，能够输出均匀位移振幅，适用于大负载超声磨削领域。
