# Dataset Card for ScreenSpot

GUI Grounding Benchmark: ScreenSpot.

Created researchers at Nanjing University and Shanghai AI Laboratory for evaluating large multimodal models (LMMs) on GUI grounding tasks on screens given a text-based instruction.

## Dataset Details

### Dataset Description

ScreenSpot is an evaluation benchmark for GUI grounding, comprising over 1200 instructions from iOS, Android, macOS, Windows and Web environments, along with annotated element types (Text or Icon/Widget).
See details and more examples in the paper.

- **Curated by:** NJU, Shanghai AI Lab
- **Language(s) (NLP):** EN
- **License:** Apache 2.0

### Dataset Sources

- **Repository:** [GitHub](https://github.com/njucckevin/SeeClick)
- **Paper:** [SeeClick: Harnessing GUI Grounding for Advanced Visual GUI Agents](https://arxiv.org/abs/2401.10935)

## Uses

This dataset is a benchmarking dataset. It is not used for training. It is used to zero-shot evaluate a multimodal model's ability to locally ground on screens.

## Dataset Structure

Each test sample contains:
- `image`: Raw pixels of the screenshot
- `file_name`: the interface screenshot filename
- `instruction`: human instruction to prompt localization
- `bbox`: the bounding box of the target element corresponding to instruction. While the original dataset had this in the form of a 4-tuple of (top-left x, top-left y, width, height), we first transform this to (top-left x, top-left y, bottom-right x, bottom-right y) for compatibility with other datasets.
- `data_type`: "icon"/"text", indicates the type of the target element
- `data_souce`: interface platform, including iOS, Android, macOS, Windows and Web (Gitlab, Shop, Forum and Tool)

## Dataset Creation

### Curation Rationale

This dataset was created to benchmark multimodal models on screens.
Specifically, to assess a model's ability to translate text into a local reference within the image.

### Source Data

Screenshot data spanning dekstop screens (Windows, macOS), mobile screens (iPhone, iPad, Android), and web screens.

#### Data Collection and Processing

Sceenshots were selected by annotators based on their typical daily usage of their device.
After collecting a screen, annotators would provide annotations for important clickable regions.
Finally, annotators then write an instruction to prompt a model to interact with a particular annotated element.

#### Who are the source data producers?

PhD and Master students in Comptuer Science at NJU.
All are proficient in the usage of both mobile and desktop devices.

## Citation

**BibTeX:**

```
@misc{cheng2024seeclick,
title={SeeClick: Harnessing GUI Grounding for Advanced Visual GUI Agents},
author={Kanzhi Cheng and Qiushi Sun and Yougang Chu and Fangzhi Xu and Yantao Li and Jianbing Zhang and Zhiyong Wu},
year={2024},
eprint={2401.10935},
archivePrefix={arXiv},
primaryClass={cs.HC}
}
```

# ScreenSpot 数据集卡片

GUI 接地基准数据集：ScreenSpot。

本数据集由南京大学与上海人工智能实验室的研究者构建，用于基于文本指令评估大型多模态模型（Large Multimodal Models, LMMs）在屏幕场景下的GUI接地任务表现。

## 数据集详情

### 数据集描述

ScreenSpot是一款GUI接地任务评估基准数据集，涵盖来自iOS、Android、macOS、Windows及Web平台的1200余条文本指令，并附带标注的元素类型（文本或图标/控件）。详细信息与更多示例请参阅相关论文。

- **数据集构建方：** 南京大学（Nanjing University, NJU）、上海人工智能实验室
- **自然语言处理所用语言：** 英语
- **许可协议：** Apache 2.0

### 数据集来源

- **代码仓库：** [GitHub](https://github.com/njucckevin/SeeClick)
- **论文：** [SeeClick：利用GUI接地技术赋能高级视觉GUI智能体](https://arxiv.org/abs/2401.10935)

## 数据集用途

本数据集为基准测试数据集，不用于模型训练，仅用于以零样本（Zero-shot）方式评估多模态模型在屏幕场景下的局部接地能力。

## 数据集结构

每条测试样本包含以下字段：
- `image`：截图的原始像素数据
- `file_name`：界面截图的文件名
- `instruction`：用于引导模型定位目标元素的人类指令
- `bbox`：与指令对应的目标元素的边界框。原始数据集采用（左上角x坐标、左上角y坐标、宽度、高度）的四元组格式，为适配其他数据集，我们已将其转换为（左上角x坐标、左上角y坐标、右下角x坐标、右下角y坐标）格式。
- `data_type`：取值为"icon"或"text"，用于标注目标元素的类型
- `data_source`：界面所属平台，涵盖iOS、Android、macOS、Windows及Web（Gitlab、电商、论坛与工具类网站）

## 数据集构建流程

### 构建初衷

本数据集旨在构建多模态模型的屏幕场景基准测试基准，具体用于评估模型将文本指令映射为图像内局部区域参考的能力。

### 源数据

源截图数据涵盖桌面端屏幕（Windows、macOS）、移动端屏幕（iPhone、iPad、Android）及Web端屏幕。

#### 数据收集与处理流程

标注人员基于日常使用设备的典型场景选取截图。采集截图后，标注人员会对其中重要的可交互区域进行标注。最后，标注人员会编写一条指令，用于引导模型与某一特定标注元素进行交互。

#### 源数据制作方

南京大学计算机科学专业的博士与硕士研究生。所有参与者均熟练掌握移动端与桌面端设备的使用方法。

## 引用格式

**BibTeX 引用格式：**

@misc{cheng2024seeclick,
title={SeeClick: Harnessing GUI Grounding for Advanced Visual GUI Agents},
author={Kanzhi Cheng and Qiushi Sun and Yougang Chu and Fangzhi Xu and Yantao Li and Jianbing Zhang and Zhiyong Wu},
year={2024},
eprint={2401.10935},
archivePrefix={arXiv},
primaryClass={cs.HC}
}
