BIN ARRANGEMENT FOR THE COLLECTING AND DISCHARGING OF SMALLER LIGNO-CELLULOSIC MATERIAL

The invention is related to a bin arrangement (1) for collecting and discharging smaller ligno-cellulosic material. The bin includes a transition part from a circular section of the bin and downwards to a rectangular section with a long and short side of said rectangular section. The transition part could be built with few wall segments， thus needing less welding. According to the invention are two rotary pocket feeders (40)， each with at least one shaft extending parallel to the long side， arranged directly under the rectangular section， enabling a uniform feed from the bin. The use of two rotary pocket feeders with this design directly under the bin do not destroy the even feed of material trough the bin part， which otherwise is experienced from using feed screws feeding material in a transverse direction from the bin outlet， and the bin do not need to have a complex bin design which converge to a small circular inlet to a conventional rotary pocket feeder.

搜集汇总

背景与挑战

背景概述

该数据集描述了一种用于收集和排放较小木质纤维素材料的料仓布置发明。该料仓设计包含从圆形到矩形截面的过渡部分，并采用两个旋转式星形给料器以实现均匀给料，避免了复杂结构需求。
