鼠骨同步辐射实验WAXD面扫描数据集（涵盖61*61组0.6s与1.6s对照数据）

人股骨WAXD也于上海同步辐射光源（SSRF）时间分辨超小角X射线散射光束线BL10U1上采集。入射X射线能量为10 keV，光束尺寸为18 𝜇𝑚×18 𝜇𝑚。数据由像素尺寸为172𝜇𝑚×172𝜇𝑚分辨率为981×1043像素的PILATUS 1M探测器收集，样品与探测器之间的距离由标样山嵛酸银（AgBH）校准为111.6毫米。实验过程中在1500𝜇𝑚×1500𝜇𝑚的正方形区域内以25𝜇𝑚的水平和垂直步长对样品进行了表征。共采集3721（61×61）帧衍射数据。

Wide-angle X-ray diffraction (WAXD) data of human femurs were also collected at the Time-resolved Ultra-small Angle X-ray Scattering beamline BL10U1 of the Shanghai Synchrotron Radiation Facility (SSRF). The incident X-ray energy was 10 keV, with a beam size of 18 μm × 18 μm. The diffraction data were collected using a PILATUS 1M detector, which has a pixel size of 172 μm × 172 μm and an image resolution of 981 × 1043 pixels. The sample-to-detector distance was calibrated to 111.6 mm using silver behenate (AgBH) as the standard reference material. During the experiment, the sample was characterized over a 1500 μm × 1500 μm square region with a step size of 25 μm in both horizontal and vertical directions. A total of 3721 (61 × 61) diffraction frames were collected.

搜集汇总

背景与挑战

背景概述

该数据集是一个关于人类骨骼的同步辐射WAXD面扫描数据集，大小为8.78GB，采用Apache 2.0许可证。用户需登录后通过SDK或GIT命令下载获取。
