2022年山西省大同市云冈石窟第18窟有限元模型数据

2022年对山西省大同市云冈石窟第18窟进行人工测量获取其点云数据，采用ANSYS、CAD、ABAQUS等软件建模，该三维模型的所有洞窟构造、佛像构造窟室分布、比例等均符合现实的云冈石窟第18窟。可用于石窟的重力分析和抗震性能分析，为石窟的维修加固提供技术支撑。

In 2022, manual measurements were conducted on Cave 18 of the Yungang Grottoes in Datong City, Shanxi Province to obtain its point cloud data. Three-dimensional modeling was carried out using software such as ANSYS, CAD and ABAQUS. All grotto structures, Buddha statue configurations, cave chamber distribution, proportions and other details of this 3D model are consistent with the actual Cave 18 of the Yungang Grottoes. This model can be used for gravity analysis and seismic performance analysis of grottoes, providing technical support for the maintenance and reinforcement of the grottoes.

搜集汇总

背景与挑战

背景概述

该数据集包含云冈石窟第18窟的有限元模型数据，通过3D激光扫描和软件建模生成，用于石窟的重力和抗震性能分析，支持石窟维护与加固工作。
