# SPIDER-COLORECTAL Dataset

SPIDER is a collection of supervised pathological datasets covering multiple organs, each with comprehensive class coverage. These datasets are professionally annotated by pathologists.

If you would like to support, sponsor, or obtain a commercial license for the SPIDER data and models, please contact us at [e-mail].

For a detailed description of SPIDER, methodology, and benchmark results, refer to our research paper:

📄 **SPIDER: A Comprehensive Multi-Organ Supervised Pathology Dataset and Baseline Models**
[View on arXiv](https://arxiv.org/abs/2503.02876)

This repository contains the **SPIDER-colorectal** dataset. To explore datasets for other organs, visit the [Hugging Face HistAI page](https://huggingface.co/histai) or [GitHub](https://github.com/HistAI/SPIDER). SPIDER is regularly updated with new organs and data, so follow us on Hugging Face to stay updated.

---

### Overview
SPIDER-colorectal is a supervised dataset of image-class pairs for the colorectal organ. Each data point consists of:
- A **central 224×224 patch** with a class label
- **24 surrounding context patches** of the same size, forming a **composite 1120×1120 region**
- Patches are extracted at **20X magnification**

We provide a **train-test split** for consistent benchmarking. The split is done at the **slide level**, ensuring that patches from the same whole slide image (WSI) do not appear in both training and test sets. Users can also merge and re-split the data as needed.

## How to Use
### Downloading the Dataset
#### Option 1: Using `huggingface_hub`
```python
from huggingface_hub import snapshot_download

snapshot_download(repo_id="histai/SPIDER-colorectal", repo_type="dataset", local_dir="/local_path")
```

#### Option 2: Using `git`
```bash
# Ensure you have Git LFS installed (https://git-lfs.com)
git lfs install
git clone https://huggingface.co/datasets/histai/SPIDER-colorectal
```

### Extracting the Dataset
The dataset is provided in multiple tar archives. Unpack them using:
```bash
cat spider-colorectal.tar.* | tar -xvf -
```

### Using the Dataset
Once extracted, you will find:
- An `images/` folder
- A `metadata.json` file

You can process and use the dataset in two ways:

#### 1. Directly in Code (Recommended for PyTorch Training)
Use the dataset class provided in `scripts/spider_dataset.py`. This class takes:
- Path to the dataset (folder containing `metadata.json` and `images/` folder)
- Context size: `5`, `3`, or `1`
- `5`: Full **1120×1120** patches (default)
- `3`: **672×672** patches
- `1`: Only central patches

The dataset class dynamically returns stitched images, making it suitable for direct use in PyTorch training pipelines.

#### 2. Convert to ImageNet Format
To structure the dataset for easy use with standard tools, convert it using `scripts/convert_to_imagenet.py`.
The script also supports different context sizes.

This will generate:
```
<output_dir>/<split>/<class>/<slide>/<image>
```
You can then use it with:
```python
from datasets import load_dataset

dataset = load_dataset("imagefolder", data_dir="/path/to/folder")
```
or

`torchvision.datasets.ImageFolder` class

---

### Dataset Composition
The SPIDER-colorectal dataset consists of the following classes:

| Class | Central Patches |
|--------------------------------|------------|
| Adenocarcinoma high grade | 6299 |
| Adenocarcinoma low grade | 6066 |
| Adenoma high grade | 5493 |
| Adenoma low grade | 5693 |
| Fat | 6081 |
| Hyperplastic polyp | 5893 |
| Inflammation | 5523 |
| Mucus | 5711 |
| Muscle | 5866 |
| Necrosis | 5481 |
| Sessile serrated lesion | 4993 |
| Stroma healthy | 8001 |
| Vessels | 6082 |

**Total Counts:**
- **77,182** central patches
- **1,039,150** total patches (including context patches)
- **1,719** total slides used for annotation

---

## License
The dataset is licensed under **CC BY-NC 4.0** and is for **research use only**.

## Citation
If you use this dataset in your work, please cite:
```bibtex
@misc{nechaev2025spidercomprehensivemultiorgansupervised,
title={SPIDER: A Comprehensive Multi-Organ Supervised Pathology Dataset and Baseline Models},
author={Dmitry Nechaev and Alexey Pchelnikov and Ekaterina Ivanova},
year={2025},
eprint={2503.02876},
archivePrefix={arXiv},
primaryClass={eess.IV},
url={https://arxiv.org/abs/2503.02876},
}
```

## Contacts

- **Authors:** Dmitry Nechaev, Alexey Pchelnikov, Ekaterina Ivanova
- **Email:** [e-mail], [e-mail], [e-mail]

# SPIDER结直肠数据集

SPIDER是一组覆盖多器官的监督式病理数据集，具备全面的类别覆盖范围，所有数据集均由病理学家进行专业标注。

若您希望对SPIDER数据与模型提供支持、赞助，或获取商业授权，请联系我们：[e-mail]。

如需了解SPIDER的详细说明、研究方法与基准测试结果，请参阅我们的学术论文：📄 **SPIDER：一款全面的多器官监督病理数据集与基准模型** [在arXiv上查看](https://arxiv.org/abs/2503.02876)

本仓库包含**SPIDER-结直肠**数据集。如需查看其他器官的数据集，请访问[Hugging Face HistAI页面](https://huggingface.co/histai)或[GitHub仓库](https://github.com/HistAI/SPIDER)。SPIDER会持续更新新增器官与数据，欢迎在Hugging Face关注我们以获取最新动态。

---

### 数据集概览

SPIDER-结直肠数据集是针对结直肠器官的图像-标签对监督数据集，每条数据包含以下内容：
- 带有类别标签的**中心224×224图像块**
- 24张相同尺寸的周边上下文图像块，共同组成**1120×1120的复合区域**
- 所有图像块均提取自**20倍放大倍率**的病理图像

我们提供了**训练集-测试集划分方案**以保障基准测试的一致性，该划分基于**玻片级别**进行，确保同一张全视野数字病理切片（Whole Slide Image, WSI）的图像块不会同时出现在训练集与测试集中。用户也可根据需求自行合并或重新划分数据集。

## 使用方法

### 数据集下载

#### 方案1：使用`huggingface_hub`库
python
from huggingface_hub import snapshot_download

snapshot_download(repo_id="histai/SPIDER-colorectal", repo_type="dataset", local_dir="/local_path")

#### 方案2：使用`git`工具
bash
# 确保已安装Git LFS（https://git-lfs.com）
git lfs install
git clone https://huggingface.co/datasets/histai/SPIDER-colorectal

### 数据集解压

本数据集以多个tar归档文件形式提供，可通过以下命令解压：
bash
cat spider-colorectal.tar.* | tar -xvf -

### 数据集使用

解压完成后，您将获得以下内容：
- `images/`文件夹
- `metadata.json`元数据文件

您可通过两种方式处理并使用该数据集：

#### 1. 直接在代码中调用（推荐用于PyTorch训练）

使用`scripts/spider_dataset.py`中提供的数据集类，该类支持以下参数：
- 数据集路径（即包含`metadata.json`与`images/`文件夹的根目录）
- 上下文块数量：`5`、`3`或`1`
- `5`：完整的**1120×1120**复合图像块（默认选项）
- `3`：**672×672**复合图像块
- `1`：仅使用中心图像块

该数据集类会动态返回拼接后的图像，适配直接集成到PyTorch训练流程中。

#### 2. 转换为ImageNet格式

如需将数据集整理为适配标准工具的格式，可使用`scripts/convert_to_imagenet.py`脚本进行转换。该脚本同样支持不同的上下文块数量设置。

转换后将生成如下目录结构：

<output_dir>/<split>/<class>/<slide>/<image>

之后您可通过以下方式加载该数据集：
python
from datasets import load_dataset

dataset = load_dataset("imagefolder", data_dir="/path/to/folder")

或使用`torchvision.datasets.ImageFolder`类

---

### 数据集构成

SPIDER-结直肠数据集包含以下类别：

| 类别名称 | 中心图像块数量 |
|--------------------------------|------------|
| 高级别腺癌 | 6299 |
| 低级别腺癌 | 6066 |
| 高级别腺瘤 | 5493 |
| 低级别腺瘤 | 5693 |
| 脂肪组织 | 6081 |
| 增生性息肉 | 5893 |
| 炎症组织 | 5523 |
| 黏液 | 5711 |
| 肌肉组织 | 5866 |
| 坏死组织 | 5481 |
| 无蒂锯齿状病变 | 4993 |
| 健康间质 | 8001 |
| 血管 | 6082 |

**总样本量：**
- **77182**张中心图像块
- **1039150**张总图像块（含上下文图像块）
- 共使用**1719**张病理玻片进行标注。

---

## 授权协议

本数据集采用**CC BY-NC 4.0**协议授权，仅可用于**学术研究用途**。

## 引用声明

若您在研究工作中使用本数据集，请引用以下文献：
bibtex
@misc{nechaev2025spidercomprehensivemultiorgansupervised,
title={SPIDER: A Comprehensive Multi-Organ Supervised Pathology Dataset and Baseline Models},
author={Dmitry Nechaev and Alexey Pchelnikov and Ekaterina Ivanova},
year={2025},
eprint={2503.02876},
archivePrefix={arXiv},
primaryClass={eess.IV},
url={https://arxiv.org/abs/2503.02876},
}

## 联系方式

- **作者**：Dmitry Nechaev、Alexey Pchelnikov、Ekaterina Ivanova
- **邮箱**：[e-mail]、[e-mail]、[e-mail]
