Raspi Flat field Images - Camera 02

Various single flat field images taken with different integrated lenses using a Raspberry Pi V2 camera at 30°C. The set contains 3669 flat field images per set in TIFF and JPEG format. Each image is approximattely16.2MB in size. Each JPEG image is 10.5MB. Each camera set is approximately 48GB in size. Images are captured in JPEG format with Bayer 10-bit raw data appended to the end of the file. This is extracted using DCRAW. Full research methodology for obtaining these images can be read in DOI:10.1016/j.diin.2019.02.002 File structure:Each compressed folder contains one camera's data. This is then segregated into subfolders which contains six folders representing each discrete lens used in the data collection process. This is combined with six pinhole lenses that were also used in the data collection process. Each of these folders is divided into a JPEG folder which contains the raw output of the sensor and a TIFF folder which contains the DCRAW converted images. The TIFF folder is then broken down into the images and a seperate folder called Fingerprint which contains the 50 images used to construct a reference pattern for the camera with that discrete lens. The image is stored as a file name "BAYERYYYYMMDD-HHMMSS.tiff" where YYYY, MM, DD, HH, MM, SS represent standard ISO time stamp format. Example Tree for Raspi01/Raspi01.zip|-- Lens-01| |--JPEG| | |-- BAYER20170926-082159.jpg| | |-- BAYER20170926-082205.jpg| | | ...| | |-- BAYER20170926-084017.jpg| || |--TIFF| | | fingerprint| | | | -- BAYER20170926-083446.tiff| | | | -- BAYER20170926-083452.tiff| | | | ...| | | | -- BAYER20170926-084017.tiff| | || | |-- BAYER20170926-082159.tiff| | |-- BAYER20170926-082205.tiff| | | ...| | |-- BAYER20170926-083440.tiff||-- Lens-02|-- Lens-03 |-- Lens-04 |-- Lens-05 |-- Lens-06 |-- Pinhole-01 |-- Pinhole-02 |-- Pinhole-03 |-- Pinhole-04 |-- Pinhole-05 |-- Pinhole-05本数据集包含使用树莓派V2摄像头（Raspberry Pi V2 camera）在30℃环境下，搭配多款集成镜头拍摄得到的各类单平场图像。每个数据集合包含3669张平场图像，格式涵盖TIFF与JPEG。单张TIFF图像大小约为16.2MB，单张JPEG图像大小约为10.5MB；每套相机采集的完整数据集总容量约为48GB。 采集所得图像以JPEG格式存储，文件末尾附加有10位拜耳（Bayer）原始raw数据，可通过DCRAW工具完成提取与转换。获取该数据集的完整研究方法可参阅DOI：10.1016/j.diin.2019.02.002。 ### 文件结构说明 每个压缩文件夹对应一台相机的采集数据。压缩包内的数据被划分为若干子文件夹，其中包含6个分别对应数据采集流程中使用的独立镜头的文件夹，以及6个针孔镜头采集用文件夹。每个镜头子文件夹下进一步分为JPEG与TIFF两个子文件夹：JPEG文件夹存储传感器原生输出的图像，TIFF文件夹存储经DCRAW转换后的图像。TIFF文件夹内还包含一个名为Fingerprint（指纹）的独立子文件夹，其中存放了50张用于构建对应镜头-相机组合参考模式的图像。 图像文件的命名格式为`BAYERYYYYMMDD-HHMMSS.tiff`，其中YYYY、MM、DD、HH、MM、SS遵循ISO标准时间戳格式。 #### 示例目录结构（Raspi01/Raspi01.zip） |-- Lens-01 | |-- JPEG | | |-- BAYER20170926-082159.jpg | | |-- BAYER20170926-082205.jpg | | | ... | | |-- BAYER20170926-084017.jpg | | | |-- TIFF | | |-- fingerprint | | | |-- BAYER20170926-083446.tiff | | | |-- BAYER20170926-083452.tiff | | | | ... | | | |-- BAYER20170926-084017.tiff | | | | | |-- BAYER20170926-082159.tiff | | |-- BAYER20170926-082205.tiff | | | ... | | |-- BAYER20170926-083440.tiff | |-- Lens-02 |-- Lens-03 |-- Lens-04 |-- Lens-05 |-- Lens-06 |-- Pinhole-01 |-- Pinhole-02 |-- Pinhole-03 |-- Pinhole-04 |-- Pinhole-05 |-- Pinhole-05
