# Dataset Card for SA-Co/Silver

SA-Co/Silver is a benchmark for promptable concept segmentation (PCS) in images. The benchmark contains images paired with text labels (also referred as Noun Phrases aka NPs), each annotated exhaustively with masks on all object instances that match the label.

SA-Co/Silver comprises 10 subsets, covering a diverse array of domains including food, art, robotics, driving etc.

- BDD100k
- DROID
- Ego4D
- MyFoodRepo-273
- GeoDE
- iNaturalist-2017
- National Gallery of Art
- SA-V
- YT-Temporal-1B
- Fathomnet

More details on the usage of SA-Co/Silver dataset including setup, visualization and evaluation can be found in the [SAM 3 GitHub](https://github.com/facebookresearch/sam3/blob/main/scripts/eval/silver/).

## Annotation Format

The annotation format is derived from [COCO format](https://cocodataset.org/#format-data). Notable data fields are:

- `images`: a `list` of `dict` features, contains a list of all image-NP pairs. Each entry is related to an image-NP pair and has the following items.
- `id`: a `string` feature, unique identifier for the image-NP pair
- `text_input`: a `string` feature, the noun phrase for the image-NP pair
- `file_name`: a `string` feature, the relative image path in the corresponding data folder.

- `annotations`: a `list` of `dict` features, containing a list of all annotations including bounding box, segmentation mask, area etc.
- `image_id`: a `string` feature, maps to the identifier for the image-np pair in images
- `bbox`: a `list` of float features, containing bounding box in [x,y,w,h] format
- `segmentation`: a dict feature, containing segmentation mask in RLE format

- `categories`: a `list` of `dict` features, containing a list of all categories. Here, we provide the category key for compatibility with the COCO format, but in open-vocabulary detection we do not use it. Instead, the text prompt is stored directly in each image (text_input in images). Note that in our setting, a unique image (id in images) actually corresponds to an (image, text prompt) combination.

For `id` in images that have corresponding annotations (i.e. exist as `image_id` in `annotations`), we refer to them as a "positive" NP. And, for `id` in `images` that don't have any annotations (i.e. they do not exist as `image_id` in `annotations`), we refer to them as a "negative" NP.

A sample annotation from DROID domain looks as follows:

#### images

```
[
{
"id": 10000000,
"file_name": "AUTOLab_failure_2023-07-07_Fri_Jul__7_18:50:36_2023_recordings_MP4_22008760/00002.jpg",
"text_input": "the large wooden table",
"width": 1280,
"height": 720,
"queried_category": "3",
"is_instance_exhaustive": 1,
"is_pixel_exhaustive": 1
}
]
```

#### annotations

```
[
{
"area": 0.17324327256944444,
"id": 1,
"image_id": 10000000,
"source": "created by SAM3",
"bbox": [
0.03750000149011612,
0.5083333253860474,
0.8382812738418579,
0.49166667461395264
],
"segmentation": {
"counts": "[^R11]f03O0O100O2N100O1O100O100O100O100O1O100O100O100O100O100O1O10000O1O10000O1O100O10000O1O100O100O100O100O100O100O100O100O100O100O1O100O100O10000O100O100O100O101N100O1O011O0O1O101OO0010O100O1O100O2OO0100O100O100O100O100O10000O100O100O1O100O10000O1O100O100O100O10000O1O100O100O100O10000O1O10000O1O100O100O100O100O100O100O1O100O100O100O100O100O100O100O100O100O100O100O100O100O100O10000O100O100O1O100O10000O100O100O100O100O1O100O100O100O100O100O100O10O0100O100O2O000O1O10000O1O10000O100O100O100O1O100O100O100O100O100O100O100O100O100O100O100O100O1O100O100O100O10000O100O100O100O100O100O100O100O100O100O100O100O100O100O10000O100O100O100O100O100O100O1O10000O1O10000O100O1O100O100O100O100O100O100O100O100O10000O1O100O100O100O100O1O10000O10\\MP@hNo?W1U@gNk?X1W@gNh?Y1Z@fNf?Y1\\@fNc?[1^@dNb?[1`@dN_?]1b@bN^?]1e@aNZ?_1i@_NW?a1l@\\NS?d1RAXNn>h1TAVNk>k1VATNj>k1XATNg>m1YASNg>m1YASNf>m1[ASNe>m1[ASNd>m1]ASNc>m1]ASNb>l1`ATN`>i1cAWN\\>d1jA\\NV>_1oAaNP>^1RBbNn=\\1TBdNk=\\1VBdNj=1`@dNGO02P2Z1h=L_AfNj0^1g=FmC;R<EoC;Q<DPD<o;DRD<n;DQD=n;DjAnN?^1g=DhAQO?\\1h=DhAUO<W1l=EeAZO:R1P>F]ABa0h0Q>Hd@lNDV1e17S>k1iAWNW>i1hAXNW>j1gAWNY>i1fAXNY>j1eAWNZ>k1dAVN\\>k1bAVN^>k1`AVN_>l1`ATN`>m1^ATNa>o1]AQNc>P2[AQNd>P2\\APNd>Q2[AoMd>R2[AoMd>R2\\AnMd>S2ZAnMe>S2[AmMe>T2YAmMf>T2YAmMg>T2WAmMh>U2VAlMj>U2TAlMl>U2PAnMo>U2j@PNV?e4O100O100O100O100O100O100O100O100O100O100O100O100O101N100O100O10O0100O100O100O100O100O100O1000000O1000000O100O100O1O1O1O100O100O1O100O100O100O100O100O100O100O100O100O1O100O100O100O100O100O10000O100O1O100O100O100O100O100O100OkK_B]Oa=7oBEP=4YCKg<1^CNa<1bCN^<OeC1[<LhC4W<KlC4S<KoC5Q<JPD6o;JRD6n;JSD5l;LTD4l;LTD4k;MUD3k;MUD4j;LWD2i;OWD1i;OWD1h;0XD0h;1WDOh;2XDOg;1ZDNe;3[DMe;3[DNc;3]DLd;4\\DLc;5]DKb;7]DIc;7^DHa;9_DGa;9_DG`;:`DF`;;_DE`;<`DCa;=^DDa;=_DC`;>_DCa;>^DBb;[OUCiMW1n2c;YO[CeMn0V3g;TO^CeMf0[3k;POaCdM>b3Q<iNbCfM7f3V<dNeCeMKQ4`<YNgCfMAX4g<RNiCk2W<SMlCl2S<TMnCl2R<SMoCm2Q<RMQDm2n;TMRDl2n;SMTDl2k;UMUDk2k;UMVDj2i;VMXDj2h;VMXDj2g;VM[Di2e;VM\\Dj2c;VM^Dj2b;TMaDk2^;PMhDP3X;aL`CjM`1e5o:\\L^Ed3b:WLdEh3[:nKPFR4P:jKTFV4k9hKXFX4h9hKXFX4g9hKYFY4f9hKZFX4f9hKZFX4e9iKZFW4g9iKXFX4g9iKPElN\\O\\5c;iKeDYOEo4f;iK]DAJh4g;iKTDJ3^4i;jKkCO;X4i;hMVDX2j;hMUDY2j;iMUDW2k;iMTDW2l;kMSDU2m;kMRDV2m;lMRDT2n;mMPDT2P<mMoCS2P<oMnCR2R<V4O100O100OiInCR2Q<kMWDQ2i;kM_DQ2`;lMoDi1Q;TNWEg1h:XN^Ed1a:\\NdE`1\\:^NjE^1U:aNPF]1o9aNUF]1k9bNXF\\1g9dN]FY1c9fN`FX1_9hNdFV1\\9iNhFT1W9lNmFQ1S9nNQGo0n8QOTGn0l8ROWGk0h8UO[Gi0e8VO^Gh0a8YO`Gf0`8YOcGe0\\8\\OeGc0[8\\OiGa0V8@lG>T8AnG>Q8BQH=o7CRH<m7DVH:j7FWH9h7HYH7g7H[H7d7J^H4b7L^H4b7K`H4_7MbH2^7NcH1\\7OfH0Z70gHOX72iHMW73jHLV74jHLU74mHKS75mHKS75nHJR76oHIQ77oHIR7jMkDP1U4U1S7RM_D0h0g1f3W1^8hNcGV1_8iNaGX1_8gNaGY1`8fNaGY1_8gNaGY1`8fNaGY1_8gNaGY1`8fNaGY1_8gNaGY1`8fNaGY1_8gNaGY1_8gNaGY1_8gNbGX1_8gNaGY1_8gNaGY1_8fNbGY1`8fNaGY1_8gNaGY1_8gNaGY1_8gNaGY1_8gNbGX1^8hNbGX1^8hNbGX1^8hNbGX1^8hNbGX1^8iNbGV1^8jNbGV1^8jNbGV1^8jNbGV1^8jNbGV1^8jNbGV1^8jNbGV1]8lNbGT1^8lNcGS1\\8nNdGR1\\8nNdGR1[8oNeGQ1Z8POfGP1X8SOhGl0W8UOiGk0U8WOkGi0S8YOmGg0P8\\OPHd0n7_ORH`0l7BTH>j7DVH<g7HYH7d7L\\H4b7N^H2`71_HO^74bHL[77eHIY7:fHFX7<hHDV7>jHBT7a0kH_OT7b0mH]OR7d0nH\\OQ7f0nH]OQ7g0oHZOQ7g0oHYOQ7h0nHXOR7h0nHXOR7h0nHXOR7i0mHWOT7h0kHYOU7h0jHXOV7h0iHYOW7g0iHYOW7h0hHXOY7g0fHZOZ7f0eH[O\\7e0cHhNlKSNa;U3bHeNSLTN\\;W3_HbN]LRNU;\\3]H^Nb8c1\\G\\Ng8c1XG\\Nj8e1TGZNo8e1PGYNS9h1lFUNW9l1gFRN]9m1bFRN`9o1^FPNe9o1[FoMg9R2WFnMj9S2TFmMn9R2RFnMn9S2PFmMR:R2nEmMS:T2kEmMU:T2jEkMX:T2gEmMY:T2fElMZ:U2dEkM^:T2aEmM_:T2`ElM`:U2^ElMc:S2\\EmMe:T2YEmMg:T2WEmMj:S2UEmMk:T2SEmMn:S2PEnMP;S2nDoMQ;R2mDoMT;Q2kDoMU;R2iDoMX;Q2fDQNY;P2eDQN[;P2cDQN^;o1`DSN_;n1^DTNc;l1[DVNd;k1ZDVNg;j1WDXNh;j1UDWNk;j1SDWNn;i1oCZNP<h1mCYNS<h1kCZNU<g1gC\\NX<e1fC\\N[<d1cC^N\\<d1aC^N_<c1^C_Na<b1\\CaNc<a1ZCaNf<_1XCcNg<_1UCeNj<^1oBfNP=]1iBiN?gL^;e4hCkNf0dLb;`8YDcGg;^8VDdGk;^8mChGR<_8bCfG_<U900001N101O00001O001O00001O00001O0O2N1O1O2N1O2N100O2N1O1O2N1O2N1O1O2N1O2M200O2M2O2N1N2O2N1N3N1O1N3N1N3M2O2kMkAkKW>Q4RBiKo=8^AR2j0`Mk=:aAP2i0bMh==eAj1g0eMf=?hAh1f0eMd=?lAg1c0gMc=`0nAe1c0hMa=a0oAd1b0iM`=a0QBc1c0iM]=c0SB`1d0iM\\=e0SB^1e0jMY=g0VB[1e0jMV=k0WBW1V`0gNn_OT1T`0lNo_Oo0S`0POS@i0P`0VOT@d0n?\\OT@`0n?@T@<o?CR@^OUN6ka0=P@XO\\N6ga0a0j@WOY?i0X3O001O00010O00001O0010O0001O00010O001O00001O001O01O01O00001O001O000O2O0O2O0O2N1O2N1O2M3MYl51fSJ3L3O1O100O1O100000000001O000000001O00000000001O01OO1000000000001O000001O000O10000000000000000O10000O10000O10000O100O1O100O1O1O1O1O1O1N2O1O1O1O1O1O1O1O1O1O1O1O1O1O1O1O1N2O1O1O1O1O1O1O100O100N21O00001O001O2N1O1O2N1O2N1O2M3N4IVT_3",
"size": [
720,
1280
]
},
"category_id": 1,
"iscrowd": 0
}
]
```

### Data Stats

Here are the stats for the 10 annotation domains. The # Image-NPs represent the total number of unique image-NP pairs including both “positive” and “negative” NPs.

| Domain | # Image-NPs | # Image-NP-Masks|
|--------------------------|--------------| ----------------|
| BDD100k | 5546 | 13210 |
| DROID | 9445 | 11098 |
| Ego4D | 12608 | 24049 |
| MyFoodRepo-273 | 20985 | 28347 |
| GeoDE | 14850 | 7570 |
| iNaturalist-2017 | 1439051 | 48899 |
| National Gallery of Art | 22294 | 18991 |
| SA-V | 18337 | 39683 |
| YT-Temporal-1B | 7816 | 12221 |
| Fathomnet | 287193 | 14174 |
