超大冰面二氧化碳跨临界制冷系统实验数据集

主要是快速滑道冰面形成理论研究和室内多功能超大冰面冰池构造的关键技术研究的模拟和实验数据。建立了冰场情景下冰面形成过程及其与室内环境关系的理论分析模型。详细揭示了浇冰、冻结、修冰等阶段的冰层内部温度分布及冰面形成过程的时间特征，阐明了多工况下外部环境参数及冰层内部结构等影响因素作用下的冰面传热传质变化规律。多功能超大冰面二氧化碳制冰系统关键技术研究与示范应用的实验数据。采用天然环保工质CO2构建了应用于国家速滑馆制冰系统的亚临界、跨临界多工况并行压缩CO2直接蒸发制冰集中式制冷系统，并且针对引射系统、热回收系统、并行压缩系统进行了较为深入的研究，攻克了亚临界、跨临界多工况并行二氧化碳集中式制冷中压回油、两段调温蓄能式热回收等关键技术难题，实现了室外宽温区多工况条件下CO2制冷系统高效满足制冰、除湿、生活热水等多种功能。室内环境精细控制关键技术研究与示范应用的模拟和实验数据。采用计算流体力学（CFD）方法对速滑馆高大空间气流组织进行建模，并通过现场测试进行了实验验证。研究了速滑馆高大空间超大冰面作用下室内环境温度场、湿度场和速度场的分布规律及影响因素作用规律，为室内环境的精细控制提供科学支撑。包括冰面和环境自动化监控的 关键技术研究与示范应用的实验数据。研究了冰面温度和环境间耦合作用，探讨了冰面温度与室内环境的在多种扰动因素及控制因素条件下的动态调控特性。建立了基于自适应控制的精准控制策略和自动监控技术方法，场馆内超大冰面与室内环境精细化监控技术是实现场馆热湿环境满足标准的重要途径。

This dataset primarily includes simulation and experimental data derived from two core research directions: theoretical studies on ice surface formation for speed skating rinks, and key technical research on the construction of indoor multi-functional super-large ice surface ice pools. A theoretical analysis model was established to describe the ice surface formation process under rink scenarios and its relationship with the indoor environment. It details the internal temperature distribution of the ice layer and the temporal characteristics of the ice surface formation process during stages such as ice watering, freezing, and ice resurfacing, and clarifies the variation laws of heat and mass transfer on the ice surface under the influence of factors including external environmental parameters and internal ice layer structure across multiple operating conditions.

The dataset also contains experimental data from key technical research and demonstration applications of multi-functional super-large ice surface carbon dioxide ice-making systems. Adopting the natural environmentally friendly refrigerant CO₂, a subcritical and transcritical multi-operating-condition parallel compression CO₂ direct evaporation ice-making centralized refrigeration system applied to the ice-making system of the National Speed Skating Oval was constructed. In-depth research was conducted on the ejector system, heat recovery system, and parallel compression system, and key technical challenges such as pressure oil return in subcritical and transcritical multi-operating-condition parallel carbon dioxide centralized refrigeration and two-stage temperature-adjustable energy-storage heat recovery were overcome. The CO₂ refrigeration system efficiently meets multiple functions including ice-making, dehumidification, and domestic hot water under outdoor wide-temperature-range multi-operating-condition conditions.

Additionally, the dataset covers simulation and experimental data from key technical research and demonstration applications of precise indoor environment control. The computational fluid dynamics (CFD) method was used to model the air distribution in the tall space of the speed skating venue, and experimental verification was carried out through on-site testing. The distribution laws of the indoor environmental temperature field, humidity field, and velocity field under the influence of the super-large ice surface in the tall space of the speed skating venue, as well as the action laws of influencing factors, were studied, providing scientific support for precise indoor environment control.

Finally, the dataset includes experimental data from key technical research and demonstration applications of automated monitoring for ice surface and environment. The coupling effect between ice surface temperature and the environment was studied, and the dynamic regulation characteristics of ice surface temperature and indoor environment under various disturbance and control factors were discussed. An accurate control strategy and automated monitoring technology method based on adaptive control were established. The precise monitoring technology for the super-large ice surface and indoor environment in the venue is an important way to ensure that the thermal and humid environment of the venue meets the relevant standards.

搜集汇总

背景与挑战

背景概述

该数据集提供了超大冰面二氧化碳跨临界制冷系统的实验与模拟数据，聚焦于冰面形成理论、冰池构造技术及制冷系统关键研究。它涵盖了国家速滑馆中采用天然工质CO2的制冷系统，包括亚临界、跨临界多工况并行压缩、热回收等关键技术，并涉及CFD建模和室内环境调控分析，旨在支持冰面与环境的精细化监控。
