Code and Video of experiment

DC-link dynamic is one of the most important issues for current source converters (CSC). In practice, the dc-link voltage suffers from the slow dynamic due to grid disturbances, which will affect the quality of output waveform and damage the converter. Many solutions have been presented to cope with it, but none of them achieve the zero dynamic dc-link voltage control. In order to fill the technical gap, a novel solution is proposed in this paper. Firstly, the impactof grid disturbances on the current source converter (CSC)is discussed with instantaneous power theory and small signal model analysis. Secondly,a new solution is presented to eliminate the adverse impacts of grid disturbances, so as to achieve the zero dynamic dc-link control concept. Meanwhile, the power quality of grid current is improved. Finally, the experiments for the proposed solution under grid disturbances are carried out with TMS320F28335DSP + XC3400FPGA digital control hardware platform. The experimental results verify the effectiveness of the proposed solution.

搜集汇总

背景与挑战

背景概述

该数据集包含实验代码（DSP代码和FPGA代码）以及实验视频，用于验证一种针对电流源变换器直流链路电压动态控制的新解决方案。其特点是通过TMS320F28335DSP和XC3S400FPGA数字平台实现零动态直流链路控制，并提供了平衡及非平衡电网跌落情况下的实验视频以证明其有效性。
